Co Extrusion Film Blowing Machine
Ruian Binhai Plastic Packing Machinery Co., Ltd.- Type：PE Film Blowing Machine
- Raw Material：PE
- Maximum Folding Width of Film：Depend on Customers
- Screw Diameter：Depend on Film Size and Speed
- Automation：Automatic
- Computerized：Computerized
Base Info
- Model NO.：BX-SJ
- Machine Weight：Depend on Machine Size
- Certification：CE, ISO9001:2008
- Film Type：LDPE, HDPE
- Machine：Two Layer Film Extrusion Machine
- Transport Package：Film Packing
- Specification：CE, SGS
- Trademark：BINHAI
- Origin：Ruian City, Zhejiang, China
- HS Code：8477309000
- Production Capacity：320sets,Year
Description
LDPE LLDPE HDPELayfat width of film(mm) 800 1000 1200 1500 Thickness of film(mm) 0.02-0.10 Max.extrusion output 75kg/h 100kg/h 120kg/h 140kg/h Screw dia(mm) Φ45x2 Φ50x2 Φ55x2 Φ60x2 Screw L/D 30:1 Screw rotation 10-100r/min Main motor(kw) 11x2 15x2 18.5x2 22x2 Dia of orifice(mm) Φ200 Φ250 Φ300 Φ350 Rir ring structure form Double air vent air ring Rotary traction form 360° 360°continuous rotation Tota power(kw) 40 45 55 70 Weight (T) 3.5 4 5 5.5 Dimension LxWxH(M) 4x3x4.4 4.2x3.2x4.6 4.6x3.4x5 5.2x3.7x6
MODLE F2B-RD-1700 F2B-RD-2000 F2B-RD-2500 F2B-RD-3000 Suitable material LDPE LLDPE HDPE Layfat width of film(mm) 1700 2000 2500 3000 Thickness of film(mm) 0.03-0.10 Max.extrusion output 140kg/h 175kg/h 200kg/h 230kg/h Screw dia(mm) Φ60x2 Φ70x2 Φ80x2 Φ90x2 Screw L/D 30:1 Screw rotation 10-100r/min Main motor(kw) 22x2 37x2 45x2 55x2 Dia of orifice(mm) Φ420 Φ500 Φ600 Φ700 Rir ring structure form Double air vent air ring Rotary traction form 360° 360°continuous rotation Total power(kw) 80 120 150 180 Weight (T) 6 8.5 11 13 Dimension LxWxH(M) 5.2x4x6.2 8x4.2x8 9x4.5x9.6 10x5x11
Optional :
Auto Loader
Embossing roller
Corona
Die rotary device
Air compressor
Manual mechanics screen
Air cooling device
Double sides winder
Buyer should be know :
1) what mateiral of your products
2) what's your products size, the Mini size and The Max.size . also the thickness
3) products usage, the rolling or piece . machine will be different when roll or piece .
4) your products need print or laminated not .
Film Blowing machine :
1) film blowing machine according to size , have many model 600mm,700mm,800mm,900mm-3000m . price will be changed according to size and optionals. larger and price higher
2) film blowing machine also can be model according to screw: 50. 55.60.65.
Questions:
1) I want to make many size , can do ?
yes, If you buy our 600mm machine , you can make film in 550mm , For example :
20CM 40CM 45CM 50CM 55CM
2) Delivery time
Usually, 15 days-20 days , If busy , 30-45 days.
3) I am newer , how to operate it .
we have video to teach you how to operate , If need, our engineer will be your factory to teach your workers , until he run machine very well .
Delivery :
1) Before delivery to your factory , machine will be run in our factory 48 hours nonstop to check everything is fine .
2) packing with shipping special oil , stretch film , some machines need wooden case.
3) when container arrive, we will take pictures and videos to you ,for you and me to tracking machines shipping .
shipping & Package
The End , thanks for your reading .
