Automatic Plastic Pipe Belling Machine/Socketing Machine (SGK200)
Zhangjiagang Yusheng Machinery Co., Ltd.- Product Type：PVC Pipe
- Screw No.：No Screw
- Automation：Automatic
- Computerized：Computerized
- Certification：CE
- Customized：Customized
Base Info
- Model NO.：SGK200
- Condition：New
- PLC：Siemens
- Oil Cylinder：Delixi
- Structure：Single-Oven or Double-Oven
- Heating Method：Heating Pipe or Ceramic Heating
- Belling Range：Od50-200mm
- Belling Type：U Type and R Type
- Pipe Length：3-6m
- Working Method：Online with The Production Line
- Cooling Method：Cooling Water or Cooling Air
- Belling R Type Method：Vacuum Pump
- Transport Package：Plastic Film,Wooden Box
- Specification：SKG200
- Trademark：Yusheng
- Origin：Zhangjiagang City (Near Shanghai), China
- HS Code：84778000
- Production Capacity：10 Sets Per Month
Description
Main technical parameterspipe expand range
out diameter Φ 90-200mm Belling type U type, R type and square type Oil label No. 46/hydraulic oil Quantity of heater 1 Heating power 9.5kw highest temperature in heater 280 Centigrade Air pressure 0.4~0.6Mpa Cooling water pressure 0.2~0.3Mpa Total power/Capacity 16kw Pipe length 3-6m Center height 1000mm± 50mm Machine set weight 3.0T
out diameter
