• Model NO.：YCQ-2L-4E
• Pneumatic Components：Parker and Festo
• Color：Orange
• Bottle Material：Pet
• Raw Material：PET
• Making Method of Parison：Injection Blowing
• Automation：Automatic
• Computerized：Computerized
• Certification：CE
• Transport Package：Wooen Pallet
• Specification：CE, SGS
• Trademark：ECENG
• Origin：Zhangjiagang, China
• HS Code：8477300000
• Production Capacity：3200-3500 Bottle Per Hour

Bottle type specification



 cavity4output(PCS/HR)3200-3500Max. volume (L)2LBottle mouth maximum overall diameter (mm)28-38mmBottle biggest diameter100mmBottle maximum height330mm
Power specifications

 Light tube quantity32pcsLight tube power1.25kwMaximum heating power40kwAll electric machine installation43kwActual consumption21.5kw
Air pressure specification

 Work pressure7-9kg/cm2Low-pressure gas consumption1600Ltr/minBlow bottle pressure25-35kg/cm2Higher -pressure gas consumption3000 Ltr/min
Frozen water specification

 Work pressure5-6 kg/cm2Temperature range10Consumption8000kcal/hrFrozen water flow88Ltr/minMachine specification
 Size of the machine4.5x1.6x1.9 (m)Weight of the machine3.5ton
After-sales service
1.we will provide the bill of load on time to make sure you can get the machine quickly
2.when you finish the Preparation conditions ,our engineer will go to your factory to install the machine ,and give you the operating manual ,and train your employee until they can operate the machine well.
3.we provide one year warranty with spare parts free.

 Transportation:
   It is located in the beautiful port city of Zhangjiagang with convenient traffic; it's about 150 km away from Shanghai.
Products:
   PVC/HDPE/PP-R pipe extrusion line, PVC & WPC profile extruding line and plastic sheet production lines with the relative auxiliary machine, PE film/ PET bottles recycling line and pelletizing lines.
Market:
   Our products have been exported to Middle East, Southeast Asia, South America and Europe etc. We received the universal confirmation and trust from our customers except of the precious experience.
Idea:
   Abide by the logos of "Sincerity, Development, innovation, Win-Win" constantly, we are honorable to cooperate with friends at home and abroad by providing the high quality products, technology and service!

   welcome to you visit our factory!!!
