Mini Type Plastic PE Film Blowing Machine
Ruian Mingde Machinery Co., Ltd.- Type：PE Film Blowing Machine
- Raw Material：PE
- Maximum Folding Width of Film：500mm
- Screw Diameter：45mm
- Automation：Automatic
- Computerized：Computerized
Base Info
- Model NO.：MD-HM
- Machine Weight：1t
- Certification：CE, ISO9001:2008
- Transport Package：Nude Packing,Wooden Case
- Specification：CE, ISO9001, SGS
- Trademark：MINGDE
- Origin：China
- HS Code：8477200000
- Production Capacity：500sets,Year
Description
HDPE,LDPE/LLDPEMax.Film Width 400MM 500mm Max.Extrusion Output HDPE:35kg/hr
LDPE:40kg/hr Blown Film Thickness HDPE:0.008-0.0.08mm
LDPE:0.02-0.10mm Extrusion Unit Hard-face Gear Case 133 146 Screw Diameter Φ35mm from Zhoushan China Φ45mm from Zhoushan China Screw Material 38 CRMOALA
38 CRMOALA Barrel's Material Screw L/D 30:1 28:1 Main Motor Power 7.5kw 11kw Frequency inverter From Delta Cylinder Cooling 250wx1 250w×2 Thermo Control (zone) 2 2 Extrusion Die Die Size HD:50mm HD:60mm Screen Changer Standard Manual Standard Manual Thermo Control (Zone) 2 2 Air Ring(mm) Φ470 Φ620 Cooling Blower(kw) 1.1 1.5 Center Steady Stick 1 pcs Take-up Unit Traction Roller Width φ138×450mm φ138×550mm Embossing Roller Width 350mm 450mm Take up Motor(kw) 0.75 Take Up Speed 10-80m/min Winding Unit Rewinding Type Single Rewinder.Surface Friction Winder Rewinding shaft Air expanding shaft Roller Width 450mm 550mm Winding Motor 10N.M 1.1kw Rewinding Speed 10-80m/min Voltage 380V,50HZ,3PHASE Machine Dimension 1400x2000x3200(mm) 1450x2280x3200(mm)
LDPE:40kg/hr
LDPE:0.02-0.10mm
38 CRMOALA
