PP Poly Bag Film Extruder Machine

RUIAN YUNBANG MACHINE CO., LTD.
  • Warranty：One Year
  • Type：PP Film Blowing Machine
  • Raw Material：PP
  • Maximum Folding Width of Film：600mm
  • Screw Diameter：55mm
  • Automation：Non-Automatic

Base Info

  • Model NO.：SJ-
  • Computerized：Non-Computerized
  • Machine Weight：1.9,3.0,4.0
  • Certification：CE, ISO9001:2008
  • Production Line：PP Bag Production Line
  • Die Head：Rotary Die Head
  • Film Max. Width：600mm , When Opne Is 1200mm
  • Transport Package：Wooden Case or Film Wrap
  • Specification：SGS, ISO9001, CE
  • Trademark：YUNBANG
  • Origin：China
  • HS Code：847730900
  • Production Capacity：900 Set,Year

Description

Technical Parameters:
TypeSJ-55SJ-60SJ-70
Diameter of Screw(mm)Φ55Φ60Φ70
Max.Layflat Width(mm)100-550200-600300-800
Film Thickness(mm)0.01-0.100.01-0.100.01-0.10
Max.Output(kg/h)404565
Screw L/D Ratio28:128:128:1
Power of Main Motor(kw)111518.5
Power of Traction Motor(kw)1.11.51.5
Overall Dimensions(L×W×H)mm4500×1100×33004800×1100×33005000×1500×3300
Weight(T)1.93.04.0
