• Model NO.：RSL-85,RSL-100,RSL-130,RSL-150,RSL-180,RSL-200
• Automation：Automatic
• Computerized：Non-Computerized
• Customized：Non-Customized
• Certification：CE, ISO9001:2008
• Condition：New
• Machine Type：plastic PE PP film pelletizing machine
• Application：Granulating Production Line
• Voltage：380V 50Hz 3Phase or customized
• Motor Brand：Siemens or customized
• Transport Package：Standard Package Plastic PE PP Film Pelletizing
• Specification：With capacity 150-1000kg,hr.
• Trademark：Mooge Tech
• Origin：Jiangsu, China
• HS Code：8477800000
• Production Capacity：30 Sets,Year for Plastic PE PP Film Pelletizing

Overview Product Description

This plastic PE PP film pelletizing machine is designed and manufactured by MOOGE TECH, which is mainly used for waste plastic PE PP soft material, such as clean HDPE, LDPE, LLDPE film flakes, clean PP woven bag, etc.

The material go through transmission system, melting system, cooling system, cutting system and collect system will turn to be clean perfect pellets for reuse.
You can choose double stage or single stage screw extruder according to the cleanliness of your raw material.
This waste plastic PP PE film pellets production line can be displayed "L" or "U" shape according to the clients' workshop.
We can also customize the pelletizing line according to client's material and product requirement.Product Parameters

RDL Series Single Stage Compacting Strand-cooling Cutting Pelletizing Line
Working Flow

Working Flow (Compacting double stage strand-cooling cutting pelletizing line for example)

---- Belt Conveyor: Feeding material into compactor. If too much scrap irons, metal detector may be needed.
---- Compactor: With multi blades crushing and compulsively compress the flakes into extruder.
---- Single Screw Extruder (first stage): Plasticizing material with high temperature and exhausting hot gas.
---- Hydraulic Screen Exchanger: Filter material impurity to make production more stable.
---- Single Screw Extruder (second stage): Further plasticizing and filtering material with high temperature.
---- Die Mold: Materials come out in long strap.
---- Water Cooling Tank: Cooling the strap with cold water.
---- Air Drying System: Drying the strap.
---- Pelletizer Cutter: Cutting the strap into pellets with high speed rotation.
---- Vibration Screen: Pick out bad pellets and keep good pellets.
---- Air Blower: Blow pellets into the silo.
---- Storage Silo: Collecting pellets.
---- Control Cabinet: Control the whole line on/off (adopt famous brand such as Schneider, Siemens, etc.)Detailed PhotosPackaging & Shipping

• For the loose cargo we will pack by wooden case.
• For the full container loading we will pack the machine by film and some on pallet accordingly.
• We can ship the machine by air or by sea.
• We will send photos of cargo loading to our clients to check and keep recording.
• We can send cargo to client's warehouse to loading.

Related ProductCompany Profile

JIANGSU MOOGE MACHINE CO.,LTDAfter Sales Service

• Pre-sale: we giveour client the detailed technician offer, sign the sales contract etc.
• In-sales: we supply the details layout, installation instruction, and technician support for the clients.
• After sales: we arrange engineer to install the machine and train the workers for our client.
• We have 24 hours service line to solve the after sales problem.
• We have free spare parts with the machine.
• We supply long term spare parts for every customer.
• We always update the new technology to every customer.
