• Model NO.：QS-A65
• Screw Diameter：65mm
• Automation：Automatic
• Computerized：Computerized
• Machine Weight：4T
• Certification：CE, ISO9001:2008
• Max. Wide：1300mm
• Rewinder Station：2
• Dia.：65
• Output：80kgs
• Motor Power：22kw
• Gear Box：200cm
• Transport Package：Seaworthy
• Specification：CE
• Trademark：QUEENSENSE
• Origin：China
• HS Code：8477309000
• Production Capacity：35,50,65,80kg,H

Characteristics:

It is used for blowing high-low pressure polyethylene, which has been widely used for producing laminating film, packing film, agricultural covering film, bag or film for textile and clothing and other packing material. The main motor adopts frequency control of motor speed to improve the speed regulating stability of main motor and save electricity by 30%. The screw and material barrel adopt 38 chrome-molybdenum aluminum which has been nitrogen treated and the traction frame adopts lifting type. No matter what size the film is, big or small, it can achieve the best effect of cooling.

Optional Equipment:

1) Auto Loader
2) Embossing Roller
3) Film Surface Treater
4) Die Rotary Device
5) Air Compressor
6) Mechanics Screen Changer
7) Up And Down.
ModelA50A55A65A65-1Diameter of screwφ50φ55φ65φ65Rcduced diameter of film(mm)100-600200-800300-1000400-1200Single-face Thickness of film(mm)0.01-0.100.01-0.100.01-0.100.01-0.10
Max.Extrusion(Kg/h)
35
50
65
80
L/D28:128:128:128:1Power of main moto(kw)111518.522Power of Tracion main moto(kw)0.751.11.51.5Heating Power(kw)15182327
Outline diameter(L x W x H) (mm)
4800 x 1900 x 41005500 x 2100 x 47006500 x 2300 x 49006500 x 2500 x 5600Weight(T)1.5T2T2.3T2.6T
