• Model NO.：EK7324
• Computerized：Computerized
• Certification：CE, ISO9001:2008
• Productivity：8000-10000 Pairs, 24hours
• Transport Package：Container
• Specification：ISO, CE
• Trademark：KCLKA
• Origin：Fujian, Jinjiang
• HS Code：84773090
• Production Capacity：20 Sets, Month

Basic Info.

Model NO. EK7324 Computerized Computerized Certification CE, ISO9001:2008 Productivity 8000-10000 Pairs/ 24hours Transport Package Container Specification ISO, CE Trademark KCLKA Origin Fujian, Jinjiang HS Code 84773090 Production Capacity 20 Sets/ Month

Product Description

PVC shoes machine



The machine is computer numerical control, driven by Hydraulic Motor, full hydraulic pressure. Hydraulic system is controlled by proportional valve. The import hydraulic parts are optimized in composition, no oil leak. Practical design, large production, low energy consuming, high degree of automatization.


Technical Description
Brief Description suitable for all kinds of thermoplastic raw materials,human engineering in design,withair blowing system,quicken production rate Item Unit

Raw material PVC.TPR
Work Stations Stations 24
Mould-clamping Pressure Tons 70
Mould space(LxWxH) Mm 600*300*260
Diameter of Screw Mm 65
Max. Injection Volume Cm3 785
Injection Pressure Kg/cm2 550
Heating bands power Kw 9.64
Temperature Control Section
Sections 4 Motor Kw/Hp 18.5/25
Total Electricity Consumption kw 30.36
Machine dimension M 4..5*3.53*2.1
Screw length diameter ratio L/D 150-220
Output Pairs/day 2500
MachineWeight Tons 6.8

Feature:
1 most of mechanical movements, covering ranges from injection, feeding, disc-rotating to mould-clamping, could be inputted into PLC, which ensures more accuracy for mechanical movements.
2 equipped with digital-type proportional controller so as to control mould-clamping pressure, injection pressure and feeding pressure.
3 unique mechanical structure, which allows to place big mould in size; at the same time, the machine is fitted with mould cooling device which is easy to operate, producing product more perfectly.
4 with the help of blowing system, the machine can have product lightweight, soft and own a polished looking in surface. Besides, the weight can be 20%-30% lower than traditional production way.
5 recycled material can be mixed together to produce products, quality of which can be comparable with new product made of purely new material.


Common FAQ:
 1.How long have you been doing it?  We started in 2003 and already have 17 years of industry experience.
 2.Are you a trading company or a manufacture?   We are manufacture .
 3.Where is your company?  Our company is located at No.30 Quanyuan Road(Wuli Park), Jinjiang
  Economic Development Zone, Jinjiang City, Fujian province, China(Mainland). The branch is located in Wushan Industrial Zone, Jinjiang City, Fujian Province.
 4.Delivery date:
  Within 20 days After receiving the 30% earnest money
 5.Payment term:
  Advance payment at order 30%, 70% before shipment
 6.What kind of technical support is provided?  Under normal circumstances, if the customer need it, we will send a technician to the factory to help install the machine. Due to the epidemic, technicians cannot go out, we will provide installation videos of related machine.
 7.What are the characteristics of EVA injection molding  machine?  Energy Saving Design: No need water circulation for mould station, using efficient heat insulator material.
