High Capacity Single Screw Twin-Screw Extruder
GPM Machinery (Shanghai) Co., Ltd.- Type：Pipe Extruder
- Plastic Processed：PVC,PP,PE,PS,ABS, etc.
- Product Type：Extrusion Molding Machine
- Feeding Mode：One Feed
- Assembly Structure：Integral Type Extruder
- Screw：Single Screw and Twin-Screw
Base Info
- Model NO.：GW
- Engagement System：Full Intermeshing
- Screw Channel Structure：Deep Screw
- Exhaust：Exhaust
- Automation：Automatic
- Computerized：Computerized
- Name：Plastic Extruder
- Other Name：Single Screw Extruder, Twin Screw Extruder
- Application：Pipe, Profile, Sheet,Board Extrusion
- Function：Single-Screw Extruder, Twin-Screw Extruder
- Motors：AC,DC
- Voltage：380V 50Hz 3phase (Customized)
- Contactor：France Schneider Contactors
- Temperature Control：Japan Omron
- Motor：Siemens Brand
- Output Capacity：1200
- Transport Package：PE Film Packaging
- Specification：according to customer requirements
- Trademark：GPM
- Origin：Shanghai
- HS Code：8477209000
- Production Capacity：1000set,Year
Description
SPECIFICATIONS FOR Single screw ExtruderExtruder model Max.output(kg/h) Total power(kw) GW45/30 40-80 15/18.5 GW50/30 80-110 18.5/22 GW65/33 200-350 55/75 GW75/33 550-650 90/110 GW90/33 750-850 160 GW120/33 950-1100 280 GW150/33 1100-1200 315
Extruder model Max.output
(kg/h) Total power(kw) GSZ45/100 40-80 15/18.5 GSZ51/105 80-110 18.5/22 GSZ55/110 120-150 22/30 GSZ65/132 280-350 37/45 GSZ80/156 380-450 55/75 GSZ80/173 500-650 75 GSZ92/188 700-850 110/132 GSZ95/196 1000 132/160
For choosing the proper machine and saving your time, please read these bellow guides carefully
1). What kinds of plastic machinery do you need ? Or what material do you want to process?
2). What capacity do you want? (kg/h )
3). What is the max and min size of the finish products .For example, the width and thickness of sheet(mm)?
4) What is the electric device you need ? Siemens, Omron or domestic ?
5) When do you want the machine? (Times for delivery)
6) Other requirements about the machine you want.
if you are interested in this machine ,please contact me:
mob : +86 13915723896 ( or +86 13817556740 )
Jeremy He
Extruder model
(kg/h)
| Specifications for Parallel twin-screw extruder | ||||||
| Model | Motor(KW) | Screw diameter(mm) | Max.speed(rpm) | L/D | Max Capacity (kg/h) | Weight (kg) |
| GSP75/28 | 37 | 75 | 36 | 28:1 | 280 | 4100 |
| GSP93/31 | 45/55 | 93 | 45 | 31:1 | 450 | 4700 |
| GSP110/31 | 90/110 | 110 | 45 | 31:1 | 680 | 6500 |
| GSP120/31 | 110/132 | 120 | 45 | 31:1 | 850 | 7500 |
| GSP135/31 | 160 | 135 | 45 | 31:1 | 1100 | 8400 |
For choosing the proper machine and saving your time, please read these bellow guides carefully
1). What kinds of plastic machinery do you need ? Or what material do you want to process?
2). What capacity do you want? (kg/h )
3). What is the max and min size of the finish products .For example, the width and thickness of sheet(mm)?
4) What is the electric device you need ? Siemens, Omron or domestic ?
5) When do you want the machine? (Times for delivery)
6) Other requirements about the machine you want.
if you are interested in this machine ,please contact me:
mob : +86 13915723896 ( or +86 13817556740 )
Jeremy He
