• Model NO.：Injection molding machine
• Structure：Horizontal
• Plastic Type：Thermoplastic
• Plasticizing Way：Screw Type
• Clamping Way：Hydraulic & Mechanical
• Automation：Automatic
• Computerized：Computerized
• Certification：CE, ISO9001:2008
• Energy Saving：Servo Energy Saving
• After Sales Service：After Sales Service
• Voltage：According to Countries
• Showroom Locate：Malaysia,Russia,Turkey,Uzberkistan
• Condition：New
• Machine Weight：11.2ton
• Transport Package：Standard Packing
• Specification：7.20x2.36x2.18M
• Trademark：HIGHSUN
• Origin：China
• HS Code：8477101090
• Production Capacity：7000sets,Year
• Package size per unit product：720.00cm * 236.00cm * 218.00cm
• Gross weight per unit product：11200.000kg

Basic Info.

Model NO. Injection molding machine Structure Horizontal Plastic Type Thermoplastic Plasticizing Way Screw Type Clamping Way Hydraulic & Mechanical Automation Automatic Computerized Computerized Certification CE, ISO9001:2008 Energy Saving Servo Energy Saving After Sales Service After Sales Service Voltage According to Countries Showroom Locate Malaysia,Russia,Turkey,Uzberkistan Condition New Machine Weight 11.2ton Transport Package Standard Packing Specification 7.20x2.36x2.18M Trademark HIGHSUN Origin China HS Code 8477101090 Production Capacity 7000sets/Year

Packaging & Delivery

Package size per unit product 720.00cm * 236.00cm * 218.00cm Gross weight per unit product 11200.000kg

Product Description

HIGHSUN PVC fitting machine, clamping force:218-1100T

1. Adopt the special designed screw & barrel for PVC material, install the air fan for cooling barrel, to avoid the material overheating and coking;
2. Increased bigger grade oil motor to facilitate PVC raw material plasticizing and molding;
3. Enlarge the width of clamping unit cover sheet, to suit PVC fitting molds (core puller cylinder) installation convenience;
4. Supply with special technical solution for PVC injection, not only modify the screw & barrel like others, but also the special solution contains complete hydraulic system and injection unit.

		HX(*)330PVC
Injection Unit
Screw diameter	mm	65
Screw L/D ratio	L/D	21
Injection capacity in theory	cm³	1062
Injection weight(PVC)	g	1274
Injection pressure	MPa	162
Injection rate	g/s	342
Plasticizing capacity	g/s	58
Screw speed	rpm	160
Clamping Unit
Clamping force	KN	3300
Moving mould-plate stroke	mm	660
Max.Mould height	mm	750
Min.Mould height	mm	250
Space between tie-bars	mm	720x670
Hydraulic ejector force	KN	125
Hydraulic ejector stroke	mm	180
Ejector number	n	13
Other
Pump pressure	MPa	16
Motor/Driving power	KW	37
Heating capacity	KW	20.35
Machine dimension	m	7.20x2.36x2.18
Machine weight	t	11.2
Oil tank capacity	L	680
