China Barrel Container Bottle Mannequin Blowing Molding Machine
Zhangjiagang Puxin Machinery Co., Ltd.- Type：Extrusion Blow Molding Machine
- Extrusion System：Hard Gear Surface Decelerator + Japan Inverter
- Auto Deflashing：Available
- Total Weight：4.2t
- Output(Dry Cycle)：1000 PC,Hr
- Die Head Option：Single, Double, Tri-Head, Tetra-Head
Base Info
- Model NO.：PXB50
- Transparent Line：Available
- Production Usage：Bottle, Toy, etc
- Multi-Layer：Available
- Multi-Color：Available
- Screw Diameter：50mm
- Raw Material：HDPE
- Making Method of Parison：Extrusion-Blow Molding
- Automation：Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008
- Transport Package：Film Packing with Wooden Bottom
- Specification：Max capacity 2L
- Trademark：Puxin
- Origin：Suzhou
- HS Code：847730100
Description
SpecificationsMaterial PE,PP, PVC, PA Max container capacity L 2 Number of die SET 1,2,3,4 Output(dry cycle) Pc/hr 1500 Machine Dimension(LxWxH) M 3.1x1.6x2.4 Total weight T 3.0 Clamping Unit Clamping force KN 46 Platen opening stroke mm 130-370 Platen size mm 300x380 Max mould size(WxH) mm 300x350 Mould thickness mm 135-210 Power Max drive KW 16.5 Total power KW 22 Fan power for screw KW 0.25 Air pressure MPA 0.6 Air consumption M3/min 0.4 Average energy consumption KW 12 Extruder unit Screw diameter mm 50 Screw L/D ratio L/D 24 Melting capacity Kg/hr 35 Number of heating zone zone 3 Extruder heating power KW 10.8 Extruder driving power KW 11 Die Number of heating zone zone 2 Power of die heating KW 4.2 Max die-pin diameter mm 75 Center distance of double die mm 130 Center distance of tri-die mm -- Center distance of tetra-die mm 75
Delivery Time:
- No later than 30 days after receipt of the deposit
Training:
- We provide training service for two or three operating men for free (but the cost for trainer's board and lodging is not included).
Installation:
- The supplier will send one specialist to test run the machine until it is running in normal state.
Guarantee:
- Our guarantee is valid for a period of 12 months. If the malfunction caused of the machine's self quality, we will troubleshoot it for free.
Auxiliary Equipments:
- Auxiliary equipments for production line are available and optional, please kindly ask for quotation.
