• Model NO.：CHSJ-PB
• Machine Weight：4.2t
• Certification：CE, ISO9001:2008
• Film Width：75-800mm
• Film Thickness(mm)：0.002-0.08mm
• Extrusion Capacity Kg/H：40-110kg,H
• L/D Ratio of Screw：30:1
• Transport Package：Wooden-Box,Nude
• Specification：SGS
• Trademark：Chengheng
• Origin：China
• HS Code：8477309000
• Production Capacity：100sets,Year

ModelPB-45/500   PB-55/700    PB-65/900  PB-75/1000Width of the film75-350mm   200-550mm  300-700mm 400-800mmThickness of the film0.002-0.08mmThe max output40kg/h   55kg/h   80kg/h  110kg/h
According to different width,thickness of film, die size and raw material characteristics to changeRaw materialPP/LDPEPower consumption10kw/h   15kw/h  20kw/h  30kw/hWeight1800kg   2800kg  3500kg  4200kgOverall dimension(L*W*H)m3.5*2.1*3.5  4.2*2.5*4.4.5*2.5*4.3  4.8*3*4.5Extruder unitDiameter of screwΦ45   Φ55   Φ65  Φ75
38CrMoALA  wearproof Alloy steel,five years guaranteeL/D ratio of screw30:1Rotation speed of screw10-120r/mBarrel FanZone 3 barrels install over-temperature fanGear box146#  173#  200#  225#
Extruder special hard gear reducer,tooth grinding teeth hardened, internal and external oil circulation systemMain motor11kw  15kw  30kw 37kw
100% Original three-phase variable frequency motor  Equipped with inverter controlDie head unitDie diameter     80mm   150mm  250mm
With 40Cr steel forging finishing, eight feed trough runner,Uniform flow channel,blown plasticizing effectCool unitAir ring typePPSingle outlet air ringAir ring materialHigh quality Taiwan cast aluminum alloy air ringBellow power1.5kw  4kw   2.2kw
Shanghai production of high-pressure mute fanTraction unitWidth of take up roller500mm  700mm   900mm   1000mm Traction roller materialsilicone roller
NBR rollerTake up motor1.5kw  2.2kw  3.0kw
Installation of RV series reducer variable frequency motor inverter controlTake up speed100m/minwater cooling systemAluminum high precision water ring
Economic water ring of iron sheetLambdoidal boardStainless steel perforated plateGusset equipmentModular rack type
Independent Split  Guide rollerAluminum guide roller (HV300-HV700) surface treatmentWinding unitWinding typeCentral receiving machineDrive typeTorque motor equipped RV reducerFilm expanding rollerSmoothing rollerElectric control cabinetlow-voltage is Universal electrical appliances, Delixi Electric, Taiwan's Yangming Electric, Huibang temperature control tableComputer control type7-inch touch screen + process control system(
Automatic air supply device

Service

Our Advantage:
1.      First-class and professional service team offer one-stop intimate service. 18 senior technical experts, more than 20 after sales service staff.
2.     No charge for training the technician, let you have nothing to worry about!
3.     Five year after-sales service and mechanical parts lifetime warranty.
4.     Life-long free for offering all kinds of technical service and 24 hours after service.(no worry about the time differences)

Order step

    step1. Please let us know which product you like. the model and size, the offers will be sent to you within 24 hours.
     step2.  We make proforma invoice (PI) for you.
     step3. Please check and confirm the PI
     step4. Once we confirmed the order, please pay it soon.
     step5. After payment, all goods will be sent to you in the delivery time.
