High Speed Automatic Blow Moulding Machine for 1000L Water Tank
Zhangjiagang Apollo Machinery Co., Ltd.- Type：Extrusion Blow Molding Machine
- Raw Material：PE
- Making Method of Parison：Extrusion-Blow Molding
- Automation：Automatic
- Computerized：Computerized
- Certification：CE
Base Info
- Model NO.：ABLD150
- Application：Bottle
- Max. Product Volume：3000L
- Blow Moulding Type：Extrusion Blow Moulding
- Place of Origin：Jiangsu, China (Mainland)
- Brand Name：Apollo
- Certificate：Ce
- Transport Package：Film Packing
- Specification：ISO9001
- Trademark：APOLLO
- Origin：China
- HS Code：8477301000
- Production Capacity：2 Set,Sets Per Month
Description
Max. Product volume
3000 liters
Screw diameter
150mm
Screw L/D ratio
33L/D
Screw drive power
132KW
Screw heating capacity
36 KW
No.of heating zone
6 zones
Output of HDPE
620-840KG/H
Oil pump drive power
75 KW
Clamping force
1800 KN
Max.size of mold
1730 X 2200mm
Mold stroke
1000-2700mm
Max.die diameter
1000mm
Blowing pressure
1.2 mpa
Air Volume
6 M³/MIN
Cooling water pressure
0.3mpa
Water consumption
240L/MIN
Size of Machine
11.5x7.5x8m
Weight of machine
72 ton
