• Model NO.：ZLRC-G
• Use：Produce FRP Grating
• Transport Package：Customized
• Specification：ISO9001, ISO14001
• Trademark：ZLRC
• Origin：Hebei, China (Mainland)
• HS Code：84799090
• Production Capacity：5 PCS, Month

Item no.Height(mm)Mesh Size
(mm)Standard Panel Sizes(mm)Bar Thickness
(top/bottom-mm)Open AreaWeight
(kg/m2)11350.8×50.83660×12206.4 / 5.476%5.521525.4×25.4 / 50.8×50.83660×12206.2 / 557%7.231538.1×38.13660×12256.3 / 5.2696.541520×20 / 40×404047×12476.35 / 5.34711.552038.1×38.13665×12256.3 / 5699.362012.8×12.8×12.8 / 38.5×38.53434×9707.2 / 6.42718.572538.1×38.13665×12256.35 / 56912.382540×404047×10076.35 / 57012.292519×19 / 38×384005×12206.4 / 54415.5102525×100(Bearing bars to run width direction)3007×10099.4 / 8(length)
6.4 / 5(width)6713.8112525.4×101.6(Bearing bars to run width direction)3660×12207 / 567131225101.6×25.4(Bearing bars to run length direction)3665×12257 / 56713.1133038.1×38.14008×15256.6 / 56814.6143040×404047×10076.6 / 56914.2153020×20 / 40×404047×12477 / 54218.1163012.7×12.7×12.7 / 38×384040×12207 / 53023.5173026×26 / 52×524011×11506.5/55613.6183838.1×38.13969×15257 / 56619.2193840×404047×10077 / 56718.82038152.4×25.4(Bearing bars to run length direction)3665×12267 / 5(length)
9 / 7(width)6820.42138101.6×38.1(Bearing bars to run length direction)3660×12207 / 57614.5223819×19 / 38.1×38.14045×12207 / 54023.5233820×20 / 40×404047×12477 / 54222244040×404047×12477 / 567202540220×602207×15077 / 5859.5264020×20 / 40×404047×12077 / 54223.7275050.7×50.73660×12258.3 / 56921.5285050.7×50.73660×12258.8 / 568%23.5295025.35×25.35 / 50.7×50.73660×12208 / 647%263050152.4×38.1(Bearing bars to run length direction)3660×12209 / 772%20.8315038.1×38.13665×122511.5 / 94840.5326338.1×38.13660×12209 / 5.858%38.5336338.1×38.13670×123012 / 946%52
Cautions:
Before use the new mold clean up oil stains and other dirt inside the mold.Before use the mold please check if the screws loose or not. If loose, please fasten in time.Keep the mold slide adequate oil, prohibit knocking the I beam steel with hammer. Spray the demoulding agent three times, spray the agent after curing the last spray.After producing 3-4 grating sheets spray the demolding agent to the mold. Produce after the agent drying. In the following production please spray the demolding agent periodically  according to the actual conditions.

Production of company
Beijing ZLRC is Chinese Fiberglass Reinforced Plastic (FRP) machines and FRP products manufacturer and fabricator for various industrial and systems for various countries. Beijing ZLRC provides the best FRP services and offerings in the fiberglass reinforced plastic industry for customers in home and abroad. Beijing ZLRC consists of teams of experienced work force to provide a wide range of FRP products, composite engineering works, services and products in order to satisfy and meet the requirement of customers.

Our factory located in the base of FRP Zaoqing town, Hengshui city Hebei province and we in FRP filed more then ten years. Our machines and FRP products customzied by customers requirements.

Our main products are: FRP tank winding machine, FRP pipe winding machine, FRP grating machine, FRP pultrusion machine, FRP grating, FRP pipe, FRP tank, FRP water tank, FRP profiles, FRP wind-proof and dust suppressing wall, FRP cooling tower and accessoires, FRP fan, FRP raw material and HVAC systems ect.

We insist on "First Quality, First Trust, and First Service" as our business philosophy, focuses on international and domestic markets, strives for excellence. We are sincerely expecting to cooperate with you and win-win, warmly welcome to visit our company; Let's create bright future together.

FAQ:
1. Q: Are you factory?
    A: Yes, we are factory that produces frp products and machines.
2. Q: Can you make the frp grating machine by customer's requests?
    A: Yes, we can customize the machine for you.
3. Q: What is the warranty?
    A: The warranty is one year.  Technical support all the time.
4. Q: What is the delivery time?
    A: Usually 15-25 days after prepayment according to the order quantity.
5. Q: Why choose you?
  A: We can provide you the good quality machine with moderate price and excellent service.
