ABC Three Layers Co-Extrusion Film Blown Extrusion Machine

HEBEI CHENGHENG PLASTIC MACHINERY TECHNOLOGY CO., LTD.
  • Type：High and Low Pressure Film Blowing Machine
  • Raw Material：HDPE
  • Maximum Folding Width of Film：3000mm
  • Screw Diameter：65mm
  • Automation：Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：CHSJ-50,55B
  • Machine Weight：8T
  • Certification：CE, ISO9001:2008
  • Extrusion Capacity Kg/H：98-160kg
  • Material：LDPE,HDPE,LLDPE,Mlldpe
  • Film Width(Folding Diameter)：300-1200mm
  • Packing Details：Wooden Cases
  • Delivery Time：25-35 Working Days
  • Film Thickness(mm)：0.007-0.05
  • Traction Speed M：15-70,Min
  • Payment Term：T,T
  • Transport Package：Wooden Cases
  • Specification：SGS
  • Trademark：CHENGHENG
  • Origin：China
  • HS Code：8477309000
  • Production Capacity：1

Description

MAIN TECHNICAL PARAMERERSSpecification/ModelSJ-3L-2500SJ-3L-2800SJ-3L-3200Suitable MaterialLDPE/LLDPE/MLDPE/HDPEFilm Width(mm)1800-23002000-26002500-3000Film Thickness(mm)0.03-0.150.03-0.150.03-0.15Max.Extrusion Output(kg/hr)220kg/hr280kg/hr350kg/hrEXTRUDERScrew Diameter(mm)Ø60/65/60Ø65/70/65Ø70/75/70Screw L/D Ratio28:128:128:1Screw MaterialSACM-645/38 CRMOALACylinder Cooling180w*6180w*6250w*6Driving Motor(kw)18.5/22/18.522/30/2237/45/37Temperatrate Control344Average Power-consume(kw)90120180DIE-HEADDie Size(mm)Ø500Ø600Ø750Temperatrate Control334Air Ring111Air Blower(kw)5.57.511TAKE-UP UNITRoller widthØ200*2500Ø220*2800Ø250*3200Effective width2300mm2600mm3000mmTake-up Speed(m/min)10-65Take-up Motor(kw)2.22.23.7WINDING UNITWinding Motor(kw)2.2kw-22.2kw-23kw-2Winding Speed(m/min)10-65Overall Dimension(L*W*H)8*3.9*8.8m8*4.1*9.3m8*4.3*10.8m


Service:

1.Free installation and ajustment.(for consumers purchase more than $100000 only)
2.Five years free after-sales service and mechanical parts lifetime warranty.
3.We will offer you the professional answers about the relating machines in 24 hours.
