Electrica Cable Copper Wire Extrusion Winding Twisting Bunching Making Buncher Recycling ...
Kunshan Fuchuan Electrical and Mechanical Co., Ltd.- Type:Pipe Extruder
- Plastic Processed:PVC, PP, PE, Sr-PVC
- Product Type:Profile Extrusion Molding Machine
- Screw:Single-Screw
- Automation:Automatic
- Computerized:Computerized
Base Info
- Model NO.:FC-45
- Sylinder Dia:45mm
- Revoling Speed of Screw:60rpm
- Extrusion Output:20kg,H
- Power for Main Machine:11kw
- Conductor Diameter:0.6-2.0mm
- Finished Wire Diameter:1.0-2.8
- Temperature Control:7phase
- Pay off Type:Dynamic or Tension Wire Feeding
- Evacuating Device:Vacuum Generator
- High Output:20kg,H
- Transport Package:Common
- Specification:ISO9001
- Trademark:FC
- Origin:China
- HS Code:8477209000
- Production Capacity:30set,One Month
Description
Basic Info.
Model NO. FC-45 Sylinder Dia 45mm Revoling Speed of Screw 60rpm Extrusion Output 20kg/H Power for Main Machine 11kw Conductor Diameter 0.6-2.0mm Finished Wire Diameter 1.0-2.8 Temperature Control 7phase Pay off Type Dynamic or Tension Wire Feeding Evacuating Device Vacuum Generator High Output 20kg/H Transport Package Common Specification ISO9001 Trademark FC Origin China HS Code 8477209000 Production Capacity 30set/One MonthProduct Description
Product Parameter:
1)Power:11kw AC motor
2)Reducer gear box:milling gear imported from Italy ZLYJ133-II,the specialized reducer gear box for extrusion
3)Screw:GH113,45MM,ratio:25:1
4)Screw drum:GH113
5)Screw speed:10-80r/min
6)Hot dip:220V voltage,3 phase screw drum,cast copper heater,each phase 2.5KW;1 phase clamp,cast copper heater,1000W.
7)Clamp type:flange bolt fix way
8)Cooling way:3 sets screw cooling high voltage centrifugal fan,60W power,the clamp cooling itself .
9)Total power:11+3*2.5+1+3*0.06=19.68KW
10)Dimension:L2000*W1300*H1500mm
11)Vacuum installation
12)Weight:800KG
13)Spare parts:1set clamp cast copper heater,2 bar hot dip
Please feel free to contact me if you have any questions.
