• Model NO.：SJ-65,28
• Condition：New
• Pipe Diameter：9~50mm
• Extruder：Sj-65,28
• Power：15kw
• Motor：Siemens
• Inverter：ABB
• Electrical Parts：Siemens
• Color：Blue
• Brand：Faygo Plast
• Transport Package：PP,PE Film
• Specification：CE&ISO9001~2000
• Trademark：Faygo Plast
• Origin：Jiangsu Zhangjiagang
• HS Code：8448900
• Production Capacity：30~150kg,H

Type
L/D
Screw Frame
Material
Screw D.
Host Power
Total power
Center Height
Produce Area
True Area
MM
KW
KW
MM
MM
M
65/28
28:1
separate type
38CrMnAl
65
15
32
1000
616
9×2.5
9-50mm PVC garden hose extrusion machine:
1.This line is suitable for producing PVC fiber reinforced pipes.
2..Meanwhile, through change and increase extruder and others device, PVC garden hose and PVC three layers fiber reinforced pipe also can be produced on this line.
3..This line manufacture the soft hose which owns such features as transparent and no poison, pressure resistance, pull-resist, corrosion-resist, beautiful outlook, soft, light and long lasting.
5..It can be widely used in sanitary foodstuff industry, It is really the best choice for transporting air, water, gas , oil and under the temperature conditions from 10 degree below zero to 65 degree above zero.

1. Single screw extruder: SJ45/28
2. Die: 6 8 10 12 14 16 (I.D)
3. Braider
4. Cooling bath
5. Drying tank
6. Haul-off unit
7. Winder
8. Electrical cabinet
two sets
six sets
one set
two sets
one set
two sets
one set
two sets
High quality PVC garden hose extrusion machine
This line is designed to produce PVC fiber reinforced hose,the wall of pipe is three layers,outer and inner layer are soft PVC hose,middle layer is Terylene fiber network, which has good chemical and physical property,It is mainly used for the transportation of high pressure of corrosive gas,and is widely used in the machinery;coal mine,oil,chemical,agriculture irrigation, gas and building.
characteristics
1.stable and reliable
2.high automation degree
3.reasonable price
4.good after-sales service
Main Technical Parameter
ModelSJ45SJ55SJ65SJ75ExtruderSJ45/30SJ55/30SJ65/28SJ75/30Diameter Range(mm)Φ6-Φ16Φ8-Φ25Φ12-Φ50Φ20-Φ50Output(kg/h)20-4030-6040-8060-110Installed Power(kw)35425065
