• Model NO.：SY-1000
• Computerized：Non-Computerized
• Certification：CE
• Volatage：Customized
• Capacity：300kg,H
• Function：Separator
• Application：Waste Treatment
• Color：Customer′s Requirement
• Power：3.6kw
• Raw Material：Copper Plastic
• Transport Package：Wooden Packing as Export Standard
• Specification：1800*1350*3500mm
• Trademark：SU YUAN
• Origin：Henan
• HS Code：8479899990
• Production Capacity：30,Month

Basic Info.

Model NO. SY-1000 Computerized Non-Computerized Certification CE Volatage Customized Capacity 300kg/H Function Separator Application Waste Treatment Color Customer′s Requirement Power 3.6kw Raw Material Copper Plastic Transport Package Wooden Packing as Export Standard Specification 1800*1350*3500mm Trademark SU YUAN Origin Henan HS Code 8479899990 Production Capacity 30/Month

Product Description

SUITABLE RAW MATERIALS

Mainly used in aluminum plastic sorting: aluminum plastic sorting of aluminum plastic plates, flexible packaging, aluminum plastic tablet packaging materials, Wahaha caps, aluminum plastic wires and other aluminum plastic composite materials; copper plastic sorting: sorting of wires and cables, waste circuit boards and bits and pieces, copper plastic pipes and other copper plastic composite materials; other convenient sorting: metal ore sorting, fly ash decarbonization sorting, slag ash metal extraction, plastic and sand sorting, tea leaf and tea rod sorting, flaxseed fruit and shell sorting, and hair and other material sorting.



PRODUCT FEATURES

The equipment carries out sorting according to the conductivity of different materials in the closed high-voltage electric field and selects materials in accordance with different physical properties, and the sorting corona electric field uses stainless steel materials plus the special corona electrode to ensure the stability of the sorting electric field.




Technical Paremeter

Model	External dimension (mm)	Rotary drum dia. (mm)	Speed (r/min)	Power (kw)	Sorting voltage (v)	Particle requirements (mm)	Weight (kg)
SY-1000	1800*1350*3500	320	30-900	3.6	20-60000	0.01-4	1250
SY-1500	2300*1350*3500	320	30-900	5.5	20-70000	0.01-4	1500
SY-1800	2650*1350*3600	320	30-900	7.5	20-80000	0.01-4	1850

WORKING PRINCIPLE

1.Feed hopper: Put the material to be crushed, so as to prevent the material from splashing out;

2.Double shaft cutting system:Using different blades according customers' material;

3.Power system:We choose famous brands of motor in China, can also be configured according to customer needs;

4.Discharging conveyor system:It adopts independent power system, and that power system is integrally fixed on the shredder by bolts, so that the power system can be integrally drawn out.



Working profermance

Packaging & Shipping


Our Service
1. We not only provide machines but also offer technical guide and market evaluate.
2. We will provide all the machines for the complete production according to customer's requirements.
3. We will provide complete service for factory layout and other information to help customer to build the factory.
4. We will provide good service for machine installation and training, until the customers can run the machines and make stably production.
5. Except one year quality guarantee, we will provide after-sell service for all the life.
6. For long-term cooperation, we always provide good quality, good price and good service to customer.


Company Information
  Xinxiang Traceability Environmental Protection Equipment Co. Ltd. was established in the end of 2002.For more than ten years, we have been committed to the research and manufacture of various waste resources separation and sorting recycling equipments. The company has always adhered to the principle of " Service First, Customer First". We will serve the new and old customers with high quality products and service. We will contribute to create a healthy and environmental world together!



FAQ

Q: Why Choose Us?

1). Several Year's Experience
We have rich experience in equipment manufacturing. Our machines have high reputation both at home and abroad (Such as the Middle East, Southeast Asia, Africa and so on more than 10 countries and regions.)
2). Manufacturer, Not Dealer
Factory direct sale makes price more competitive.Customers are always welcome to visit our factory for machine test.
3). Fast Delivery
We promise the goods can be shipped out on delivery date after confirmation of the order.
Q: How do I know the quality of your machine?
A: You can send your sample scrap materials to us and we will test the machine for you without charging the fees. And we can send the machine test video to you. We also warmly welcome you to visit our factory to test our machine personally.
Q: Which brand of motor will you use?
A: We use domestic motor manufatured by Chinese-famous suppliers, but you can choose Siemens or other brand motor. Don't worry about our machine's quality.
Q: Will you dispatch the engineer to guide installation?
A: Yes, according to the customer's requirement, we will dispatch engineers to guide installation and traning about the operation of the machine.
