• Transport Package：Pallets Package
• Specification：JY250
• Trademark：customization
• Origin：China
• HS Code：84778000
• Production Capacity：25-60

 FILM EAR MATERIAL RECYCLING
MACHINE
The main featuresUse: use for recycling ear material of extruder with above 45mm screw.
Function: crush and immediately recycle at 100% specifying for small-scale extruder or more wider PP, PE,HLPE,LOPE, shrinkage film, PE plastic wrap and other thin films, ear materials of foaming cloth.
Processing function: the ear material with thickness of 0.01-0.08mm and width of low 30mm.
These series products adopt tungsten steel to crush materials. Normally , the operation life is longer 10 times than general crushing; the working life is about 400 work days, and it needs replacing grind for usage.


Specification parameter


Models	Unit	Jy123	Jy163
Grinding Motor	Hp	1	3
Swinging Diameter	Mm	130	180
Blade Length	Mm	123	163
Number of Fixed Blade	Pc/set	2	2
Number of Rotary Cutter	Pc/set	3	3
Mesh Size	Mm	3-5	3-6
Blower Motor	Hp	2	2
Workload	Kgs/nr	15-30	25-60
Conveyor Screw Motor	Hp	1/2-1	1
Cyclone Separator	Mm	250	250
L*W*H	Mm	100*550*950	1050*600*1050
Package Size	Mm	1100*900*800	1200*1000*1100
Weight	kgs	180	300

A:Where is our factory?
We are in Zisheng street,Gaokeya Garden,Licheng District,Quanzhou City,Fujian Province.
B:How to get to our factory?
(1)You can get to the Jinjiang airport directly,then,connecting us and we will pick you up by car
(2)You can take the train to Quanzhou station,then,we will pick you up by car
C:Why choose us?
(1)We have complete system of designing of our equipment
(2)We can provide the perfect management solutions
(3)We could make you in a leading position in the industry
D:What's the payment method?
L/C,T/T,Western union
E:Can we see the running machine in ur factory?
Yes.Before making your decision buying the equipment or not,you can bring some material here to test-run the equipment
F:How long of the warranty time?
Our warranty period is 1 year
