• Model NO.：HSD160-315mm
• Condition：New
• Raw Material：PE
• Calibration Method：Vacuum and Water Spraying
• Cutting Method：Planetary Cutting
• PLC：Siemens
• Transport Package：Standard Export Packing
• Specification：Pipe diameter from160mm to 315mm
• Trademark：HSD
• Origin：Qingdao, China
• HS Code：8477209000
• Production Capacity：280-400kg,H for Different Sizes of Pipes

Basic Info.

Model NO. HSD160-315mm Condition New Raw Material PE Calibration Method Vacuum and Water Spraying Cutting Method Planetary Cutting PLC Siemens Transport Package Standard Export Packing Specification Pipe diameter from160mm to 315mm Trademark HSD Origin Qingdao, China HS Code 8477209000 Production Capacity 280-400kg/H for Different Sizes of Pipes

Product Description

PE Pipe Extrusion Line/ Pressure Pipe Production Line/ Plastic Extruder (160-315mm)

---Pipe diameter range: 160-315mm
---The extrusion line comprise equipments and devices as below,
1set Vacuum loader
1set Hopper dryer
1set High-effeciency single screw extruder
1set 25/25 single screw extruder for mark line
1set Vacuum calibration table
2sets Water spraying tank
1set Hauling machine
1set Cutting machine
1set Stacker





I. Pipe advantages and Usage
---HDPE water supplying pipe is with advantages of good hot melt, flexibility, corrosion resistance, and aging tolerance.
---- HDPE pipe is widely used in municipal water supplying, city gas transportation and other areas.

II. Main machine- High-effeciency single screw extruder
---Single screw is with barreir & mixing head; Barrel is new model with slotting (channel), Both make security of good jellification, large output and stable performance.

III. Spiral dihead & 25/25 co-extruder for mark line
---Diehead is spiral model. It has advantages of low melt temperature, good mixing, low cavity pressure, and stable performance.
----Special calibrating and cooling system. We use water film lubrication and water-ring cooling to fit for requirements of HDPE and PP material, to make sure accurate diameter and roundness of thick wall pipe when they are extruded at high speed.

IV. Controlling system
The complete line could be controlled by PLC, with good human-machine interface, all technical parameters could be set and indicated by touching screen. Controlling system is designed according to the customer; S requirement, to be with PLC, or without.




Style	PE16/63	PE75/250	PE160/315	PE200/450	PE-315/630	PE-500/800	PE-710/1200
Main extruder	SJ-65/30	SJ-75/33	SJ90/33	SJ90/33	SJ-120/33	SJ-120/33	SJ-150/33
Main motor	55kw	90kw	132kwDC	160kwDC	185kwDC	250kwDC	400kwDC
Pipe diameter	Φ16-63mm	Φ75-250mm	Φ160-315mm	Φ200-450mm	Φ315-630mm	Φ500-800mm	Φ710-1200mm
Capacity	80-100kg/h	180-250kg/h	280-400kg/h	350-500kg/h	450-600kg/h	700-900kg/h	800-1200kg/h
