• Model NO.：FDS930A , FDS1100A
• Condition：New
• Application：EPS Foam for EPS Plant
• Warranty：1year
• Transport Package：Standard Export Package
• Trademark：VST
• Origin：Zhejiang, China (Mainland)
• Production Capacity：20 Unit , Month

Basic Info.

Model NO. FDS930A / FDS1100A Condition New Application EPS Foam for EPS Plant Warranty 1year Transport Package Standard Export Package Trademark VST Origin Zhejiang, China (Mainland) Production Capacity 20 Unit / Month

Product Description

Main Features:

1, All process including filling, expanding, sieving, delumping and conveying to silos are done automatically.

2, With primary and secondary expansion device to get density of 8-30g/l

3, Fist filling is controlled by frequency converter

4, With power-off protection device

5, With Japan steam presure reducing valve

TECHNICAL DATA
Item		FDS930A	FDS1100A
Expansion Chamber	Diameter Volume Useable volume	Dn900 0.9 m³ 0.75m³	Dn1100 1.4 m³ 1.0m³
Steam	Entry Consumption Pressure	DN50 4-6kg/cycle 0.6-0.8MPa	DN50 6-8kg/cycle 0.6-0.8MPa
Compressed Air	Entry Consumption Pressure	DN50 0.5-0.7m3/cycle 0.5-0.8MPa	DN50 0.9-1.1m3/cycle 0.5-0.8MPa
Drainage	Upper drain port lower drain port lower steam vent	DN100  DN100 DN80	DN100 DN100 DN80
Capacity	10g/l 15g/l 20g/l 30g/l	230g/l 320g/l 450g/l 670g/l	320g/l 550g/l 750g/l 850g/l
Material Conveying Line		DN150	DN150
Connected Load		17Kw	19Kw
Expanded Density		10~50 m3	10~40 m3
Overall  Dimension	(L*W*H)	2700*4200*5900(mm)	2900*4500*5900(mm)
Weight		2700kg	3200kg
Room Height Required		3000mm	3000mm
