Best Quality High End China Made Wholesale 3 Layers Film Machine

Ruian Mingde Machinery Co., Ltd.
  • Type：Three-Layer Co-extrusion Film Blowing Machine
  • Raw Material：LDPE
  • Maximum Folding Width of Film：2000mm
  • Screw Diameter：50-65mm
  • Automation：Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：MD-3L
  • Machine Weight：8T
  • Certification：CE, ISO9001:2008
  • Min. Film Width：1200mm
  • Max. Film Width：2000mm
  • Color：Green and White
  • Transport Package：Wooden Case
  • Specification：CE
  • Trademark：MINGDE
  • Origin：China
  • HS Code：8477200000
  • Production Capacity：10sets,Year

Description

LDPE LLDPE HDPEFilm width800-1300mm800-1500mm1200-2000mm1500-2500mmFilm thickness0.028-0.18mm0.028-0.18mm0.03-0.18mm0.05-0.15mmOutput80-130kg/hr190kg/hr260kg/hr300kg/hrExtruder  Screw diameterΦ45/50/45mmΦ50/55/50mmΦ55/65/55mmΦ65/70/65mmL/D28:1Screw materialSACM-645/38 CRMOALABarrel materialSACM-645/38CRMOALABarrel cooling370W×2370W×2550W×3550W×4Main motor power15/18.5/15Kw18.5/22/18.5Kw22/37/22Kw37/45/37KwBarrel temperature control3444Total power58Kw70Kw90Kw130KwDie part Die sizeΦ250/200mmΦ300/250mmΦ350/400mmΦ600mmTemperature control zone4444Air ring1Fan power5.5Kw7.5Kw11Kw11KwTraction part Traction rollerΦ165×1400mmΦ165×1600mmΦ180×2000mmΦ220×2600mmTraction width1300mm1500mm2000mm2500mmTraction700mmTraction speed10-65m/min10-65m/min10-65m/min10-40m/minTraction power1.5Kw1.5Kw2.2Kw2.2KwWinding part Winding motor1.51.5kw2.2kw30N.mWinding speed10-65m/min10-65m/min10-65m/min10-65m/minMachine size7.5×5.5×7m8.2X5.8X7m9.0×6.4×8.2m8.5×7.2×10
