• Model NO.：TPWL300~3000
• Computerized：Customized
• Certification：ISO9001:2008, CE
• Color：Could Be Customized
• After-Sale Service：Eers Available to Service Machinery Overseas
• Material of Recycling Machines：Stainless Steel
• Electric Grid：3p 220V~440V 50 or 60Hz
• Transport Package：Wrap Film
• Specification：TSWL300~3000
• Trademark：RETECH
• Origin：China
• HS Code：8477800000
• Production Capacity：300~3000kg,H

No.Name Motor PowerDimension WeightNecessity1Belt conveyer1.5~2.2kw4000*700*3000mm450kgNecessary 2Mechanical label separator18.5~22kw3200*1200*2500mm4000kgNecessary3Manual sorting 1.5~3.7kw6000*1000*1200mm600kgOptional 4Metal detector0.4kw2000*1300*1600mm350kgOptional5Belt conveyer1.5~2.2kw4000*700*3000mm450kgNecessary 6Wet crusher22~90kw1700*1600*3200mm3500kgNecessary7Screw conveyer2.2~5.5kw3300*450*2700mm400kgNecessary 8Cold rinsing washer3~5.5kw5500*1900*2200mm2300kgNecessary9Screw conveyer2.2~5.5kw3300*450*2700mm400kgNecessary10Hot washer3~7.5kw1800*1800*2100mm2500kgNecessary11Screw conveyer 2.2~5.5kw3300*450*2700mm400kgNecessary12High speed friction washer22kw~37kw3000*900*1700mm2700kgOptional 13Screw conveyer 2.2~5.5kw3300*450*2700mm400kgNecessary14Cold rinsing washer 3~5.5kw5500*1900*2200mm2300kgNecessary15Screw conveyer 2.2~3.7kw3300*450*2700mm400kgNecessary16Vertical dewatering machine45~55kw/1800*1800*2000mm2200kgAlternative17Drying system22kw~30kw3000*2200*1800mm420kgOptional 18Air label separator 3kw~7.5kw1800*1000*3600900kgOptional19Storage silo--- 1600*1600*3800mm380kgNecessary20Electric panelCustomized 3000*600*1500mm170kgNecessary
Advantages of our Washing Recyling Machines:

Safety: All our machines are made according to the CE standard. All rotating parts with safe fence or cover in case of any men body damaged. The maintenance opening parts are equipped with limited switch. All lines are quipped with emergency switch.
Material: All parts contacted with material are made of stainless steel SUS304 with thickness 3~6mm.
Long-life running: All steel parts are treated with anticorrosion, all stainless steel are SUS 304 with acid washing treatment.
Designing: All plants designed base on the real situation of customers' material and our many years experience manufacturing the machines.
Energy saving: With reasonable designing to the structure of the plant, it can not only wash the material clean but also can help the custom to save power consumption which means to help customer create more profit.

360°services:

Customer requirements →Scheme designed →confirmed by customers →order fixed →manufacturing →trial running in our factory →confirmed by customers →shipped →engineer available overseas →whole life after sales services

Q&A about recycling machines:

1. What is the function of the PET bottle washing recycling plant?
The PET bottle washing recycling plant is mainly used to process PET beverage bottles. The line includes two functions, one function is to separate the PE caps and PVC or PP caps out to get pure PET flakes finally. The other one function is to wash the PET flakes clean, at end to get clean flakes.
2. What are main parts of the PET bottle washing recycling plant?
The PET bottle washing recycling plant is mainly consists of:
Belt conveyer--- bale opener--- belt conveyer-pre-washer--- belt conveyer--- mechanical label separator--- manual sorting--- metal detector--- belt conveyer--- crusher--- screw conveyer--- floating washer--- screw conveyer--- hot washer--- screw conveyer--- high speed friction washer--- screw conveyer--- floating washer--- screw conveyer--- vertical dewatering machine--- drying system--- zigzag label separator--- storage silo--- operating panel
The up structure of the flowing chart is just a standard we recommend, it can be adjusted due to the customers' material situation and requirements.
3. What capacity of the PET bottle washing recycling plant?
300-3000kg/h for single washing line
4. What power of the PET bottle washing recycling plant?
150kw~350kw
5. How much water does it need of the PET bottle washing recycling plant?
3~8T per hour
6. How large space does it need for a PET bottle washing recycling plant?
100~400 square meters
7. Do you offered training of the PET bottle washing recycling plant?
Yes, we can training your worker.
8. Can you send engineers to our factory to help us install the PET bottle washing recycling plant?
Surely it is no problem.
9. Do you offer all the documents for the PET bottle washing recycling plant? Such as the manual operating.
Yes, we will offer you the complete documents for the PET bottle washing recycling plant.
10. What is the situation of the final products from the PET bottle washing recycling plant?
The PET flakes from the PET bottle washing recycling plant moisture level lower than 1%, the PVC level lower than 200PPM, the dirties level lower than 300PPM.
11. What certifications do you have for the PET bottle washing recycling plant?
We have CE and ISO9001 certification for the entire PET bottle washing recycling plant.
12. What is material of the PET bottle washing recycling plant?
The parts contacted with water are made of stainless steel SUS 304 for the entire PET bottle washing recycling plant.
13. Does it easier and costly to maintenance for the PET bottle washing recycling plant.
It is easier and not costly. We will train your workers and offer the manual operating.
14. What about the electrics of the PET bottle washing recycling plant?
Our standard electric parts are famous brand, such as Siemens Contactor, Fuji inverter… and also they are customized for the PET bottle washing recycling plant.
15 workers needed for the PET bottle washing recycling plant?
4-12 people
