1700mm HDPE LDPE LLDPE Film Blowing Machine
Xiongqiu Plastic Machinery Co., Ltd.- Type：High and Low Pressure thin Film Blowing Machine
- Raw Material：HDPE
- Maximum Folding Width of Film：1600mm
- Screw Diameter：75mm
- Automation：Non-Automatic
- Computerized：Computerized
Base Info
- Model NO.：FM-1700
- Machine Weight：8T
- Certification：CE, ISO9001:2008
- Size(M)：6.0*3.66*6.5
- Voltage：380V 50Hz 3phase
- Transport Package：Plastic Film for Container Shipment
- Specification：single layer
- Trademark：Xiongqiu Plastic Machinery Co., Ltd.
- Origin：Foshan, Guangdong Province
- HS Code：8477300000
Description
Basic Info.
Model NO. FM-1700 Machine Weight 8T Certification CE, ISO9001:2008 Size(M) 6.0*3.66*6.5 Voltage 380V 50Hz 3phase Transport Package Plastic Film for Container Shipment Specification single layer Trademark Xiongqiu Plastic Machinery Co., Ltd. Origin Foshan, Guangdong Province HS Code 8477300000Product Description
It is used to blow various plastic film of LDPE, HDPE and LLDPE, etc.. Widely used in packing food stuff, garment and textile, daily product, industrial products and agricultural field.| model | suitable material | film width | thickness | max output | screw diameter | L/D ratio | temp. controller | barrel cooling | driving motor |
| FM-1700 | LDPE/HDPE/LLDPE | 1600mm | 0.02-0.20mm | 105kgs/hr | Φ75mm | 30:1 | 5 zone | 250w*3 | 30kw |
| die diameter | air ring diameter | cooling fan | take up width | effective width | take up motor | winder width | effective width | winder moto |
| Φ160mm | Φ300mm | 3.7kw | 1700mm | 1600mm | 2.2kw | 1700mm | 1600mm | 50kg |
| die structure | spiral mandrel die chrome plated surface 40Cr |
| optional equipment | auto-loader device, film surface treater, air compressor, fast change net, double center winder/cage roll flat winder, rotary die head, double wind air ring |
other pictures for reference:
