• Model NO.：MD-3L65
• Machine Weight：8000kg
• Certification：CE
• Suitable Material：LDPE LLDPE EVA HDPE
• Transport Package：Film Packing
• Specification：9000*4200*9000mm
• Trademark：Mingde
• Origin：China, Zhejiang

MD-3L series three-layer co-extrusion film blowing machine
 Main Technical ParametersModelMD-3L50MD-3L55MD-3L65 Suitable MaterialLDPE   LLDPE   EVA  HDPE Max Film Width(mm)120015002000 Film Thickness(mm)LD:0.015-0.15 Max Extrusion Output LD140kg/hr200kg/hr280kg/hr Extrusion unit  Gear Box146/173/146173/200/173200×3 Screw Diameter(mm)φ50/55/50φ55/65/55φ65/65/65 Screw L/D Ratio28:1 Screw's Material38 CRMOALA Barrel's Material38 CRMOALA Barrel's Cooling Fan370W×2×3370W×2×3370×3×3 Thermo Control (zone)3×33×34×3 Driving Motor (kw)15/22/1522/30/2230/30/30 Extrusion Die   Die Size (mm)LD:φ250/300LD:φ350/400LD:φ500 Rotary Die Head (mm)360°Continue Rotary  360° Screen ChangerManual Mechanics Screen Changer Thermo Control (zone)344 Air Ring 1 PCS Cooling Blower (kw)5.57.511 Take-UP Unit   Roller Width (mm)φ165×1300φ165×1600φ190×2100 Take-UP Motor (kw)1.51.52.2 Take-UP Speed(M/min)5-605-605-60 Winding Unit   Type OF WinderSurface Friction Double Winder Roller Width (mm)130016002100 Winding Motor 16N.M1.5kw1.5kw Winding Speed(M/min)5-605-605-60 Voltage380V, 50HZ, 3PHASE Cover Dimensions (m)6.8×2.6×6.57.5×3.2×7.59×4.2×9
OPTIONAL EQUIPMENT   1)AUTO LOADER×3   2)Chiller    3)CORONA    4)FULL AUTOMATIC WINDER   5)EMBOSSING ROLLER
