Ce Certificated Zhejiang Supplier Direct Selling Big Sized Best Quality and Fast Speed ...
Zhejiang Songshan Machinery Co., Ltd.- Raw Material：HDPE, LDPE, LLDPE; Virgin and Recycled
- Screw Diameter：100mm
- Certification：Ce ISO SGS
- Film：Ruian Film Blowing Extruder
- Condition：New
- film Thickness：0.01mm-0.25mm
Base Info
- Model NO.：SJ-100
- Warranty：1year
- Blower：7.5kw
- Automatic：No
- Blow Moulding Type：Extrusion Blow Moulding
- Power(W)：75kw
- Ld Ratio：32:1
- film Width：2000mm
- Transport Package：Plastic Film; , Wooden Boxes, or as Required
- Trademark：songshan
- Origin：Zhejiang, China (Mainland)
Description
Model
SJ-85
SJ-100
SJ-120
Features
Raw Material
HDPE, LDPE, LLDPE; Virgin and Recycled
Film Width
1800mm
2000mm
3000mm
Average Output
120Kgs
200Kgs
300Kgs
Film Thickness
0.01mm-0.25mm
Power supply
380V, 3Phase, 50Hz
Dimension
8×6×7M
8×6×7M
9×7×11M
Extrusion Unit
Screw Diameter/LD ratio
85mm
32:1
100mm
32:1
120mm
32:1
Motor
55KW
75KW
110KW
Gearbox
225
250
300
Die Head Type
Rotary Die Head
Die Size
500mm
600mm
800mm
Film
Taking-up
Tower
Upper Tower
Gusseting; rollers open and close controlled by air cylinder
Roller Length
2000mm
2400mm
3400mm
Winding Station
Winder Type
Back to back double winding station fraction type
Rollers
2000mm
2400mm
3400mm
Winding Diameter
650mm
Control Panel
Electronics
Top China Brand
