Sj-55 Factory Selling Good Quality HDPE LDPE LLDPE Film Blowing Machine Extruder for ...
Zhejiang Songshan Machinery Co., Ltd.- Raw Material：HDPE, LDPE, LLDPE; Virgin and Recycled
- Screw Diameter：55mm
- Certification：Ce ISO SGS
- Condition：New
- Warranty：1year Guarantee
- film Thickness：0.01mm-0.15mm
Base Info
- Model NO.：SJ-55-65
- Blower：3kw
- Automatic：No
- Die Size：80,160mm
- Blow Moulding Type：Extrusion Blow Moulding
- Power(W)：15kw
- film Width：800mm
- Weight：1950kg
- Transport Package：Plastic Film; , Wooden Boxes, or as Required
- Trademark：songshan
- Origin：Zhejiang, China (Mainland)
Description
Model
SJ-50
SJ-55
SJ-65
Features
Raw Material
HDPE, LDPE, LLDPE; Virgin and Recycled
Film Width
600mm
800mm
1200mm
Output
30Kgs
40Kgs
65Kgs
Film Thickness
0.01mm-0.15mm
Dimension
4×3×4M
5×3.5×4.5M
6×4×5.5M
Extrusion Unit
Screw Diameter/LD ratio
50mm
28:1
55mm
30:1
65mm
30:1
Motor
11KW
15KW
22KW
Gearbox
133
146
173
Die Head Type
Fixed Die Head
Die Size
50/80mm
80/160mm
160/260mm
Taking-up Tower
Upper Tower Type
Up and down; embossing roller and gusseting
Roller Length
700mm
900mm
1400mm
Roller Working Way
Opened and Tightened By Air Cylinders
Winding Station
Winder Type
Single winding fraction type
Rollers
700mm
900mm
1400mm
Winding Diameter
650mm
Control Panel
Electronics
Top China Brand
This film blowing machine is to satisfy the customer's requirements of high quality, high output film blowing equipment. Compared with kindred equipment, it has the advantages such as more compact structure, higher output, better produce quality, less energy consumption, easier operation. and create the considerable economic benefit for you.
