Color Stripe Film Blowing Machine

Ruian Mingde Machinery Co., Ltd.
  • Type：PE Film Blowing Machine
  • Raw Material：PE
  • Maximum Folding Width of Film：600mm
  • Screw Diameter：45mm
  • Automation：Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：MD-45*2
  • Certification：CE, ISO9001:2008
  • Output：55kg,Hr
  • Transport Package：Film Packing
  • Trademark：Mingde
  • Origin：China

Description

Basic Info.

Model NO. MD-45*2 Certification CE, ISO9001:2008 Output 55kg/Hr Transport Package Film Packing Trademark Mingde Origin China

Product Description


Specifications

Two color film blowing machine: can make front and back two color film.



DESCRIPTION&SPECIFICATION
Material suitable:LDPE
Film width:1000mm
Film thickness:50mic
Screw diameter:Φ50mmX2pcs
Screw L/D ratio:28:1
Screw and barrel material:38crmoala
Gear box:146X2pcs
Die diameter:Φ250mm
Thermo control zone:5
Thermo control of barrel:4
Thermo control of die:2
Barrel cooling fan:250wx2pcsX2lines
Main motor power:18.5kwX2 with inverters
Max.output:100kg/hr
Die cooling Blower power:3kw
Length of take up roller:1100mm X2pcs,one rubber roller, one steel roller
Diameter of take up roller: Φ165mm
Banana roller : Φ165mmX1100X2pcs
Take up motor power:1.1kw with inverter
Take up speed:0-50m/min
Machine height:5meter
Max.dia of winding roller:600mm
