Three to Five Layers Co-Extrusion Film Blowing Machine Set
Ruian Mingde Machinery Co., Ltd.- Type：Three-Layer Co-extrusion Film Blowing Machine
- Raw Material：PE
- Maximum Folding Width of Film：1200mm
- Screw Diameter：55mm
- Automation：Automatic
- Computerized：Computerized
Base Info
- Model NO.：3SJ55-MD1300
- Certification：CE, ISO9001:2008
- Output：120kg,Hr
- Screw L/D Ratio：30:1
- Transport Package：Film Packing
- Trademark：Mingde
- Origin：China
- HS Code：8477800000
Description
Model
3SJ55-MD1300
3SJ60-MD1500
3SJ65-MD1800
3SJ70-MD2300
Film width
1200mm
1400mm
1700mm
2100mm
Film layer
3
Film thickness
0.02-0.12mm
Output
200kg/hr
250kg/hr
300kg/hr
400kg/hr
Suitable material
LLDPE LDPE EVA
Screw diameter
Φ45/Φ55/Φ45mm
Φ50/Φ60/Φ50mm
Φ60/Φ70/Φ60mm
Φ75/Φ90/Φ75mm
Screw L/D
L/D 30:1
Screw speed
100r/min
Main motor power
18.5/30/18.5kw
22/37/22kw
30/45/30kw
55/90/55kw
Die structure
ICB film tube inner cooling system
Air-ring structure
Double vents air ring
Reversting haul-off system
horizontal±180°
Take-up wide up speed
45-120m/min
Total power
150kw
280kw
280kw
280kw
Machine size
Acording to actual machine
Machine weight
