LDPE HDPE Single Layer Blown Film Extrusion Machine

RUIAN YUNBANG MACHINE CO., LTD.
  • Type：PE Film Blowing Machine
  • Raw Material：PE
  • Maximum Folding Width of Film：600mm
  • Screw Diameter：50mm
  • Automation：Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：SJ
  • Machine Weight：1.5t
  • Certification：CE, ISO9001:2008
  • Screw Ratio：L,D 28:1
  • Screw Speed：10-100r,Min
  • Folding Width of Film：100-600mm
  • Single-Sided Thickness of Film：0.01-0.10mm
  • Max. Extrude Output：35kg,H
  • Transport Package：as Requirement
  • Specification：CE. SGS
  • Trademark：YunBang
  • Origin：China
  • HS Code：8477309000
  • Production Capacity：20 Sets,Month

Description


Model SJ-50SJ-55SJ-60 SJ-65 Screw Diameter    Φ50mm  Φ55mm  Φ60mm  Φ65mmScrew Ratio L/D 28:1  L/D 28:1  L/D 28:1  L/D 28:1Screw Speed  10-100r/min  10-100r/min  10-100r/min  10-100r/minFolding Width Of Film 100-600mm200-800mm 300-1000mm 400-1200mm Single-sided Thickness Of Film 0.01-0.10mm  0.01-0.10mm  0.01-0.10mm  0.01-0.10mmMax. Extrude Output 35kg/h50kg/h 65kg/h 80kg/h Power Of Main Motor 7.5kw11kw  15kw18.5kw Power Of Traction Motor 1.1kw1.1kw 1.5kw 1.5kw Heating Power 11kw 13kw19kw 21kw Overall Dimensions (L*W*H) 4800×1900×3500mm5500×2100×3800mm 6500×2300×4200mm 6500×2500×6000mmWeight 1.5T2T 2.3T 2.6T  Suitable Raw Material PE  PE  PE PE
