• Model NO.：ssw
• Raw Material：PET
• Making Method of Parison：Injection Blowing
• Automation：Automatic
• Computerized：Non-Computerized
• Certification：CE
• Transport Package：Carton
• Specification：CE
• Trademark：ssw
• Origin：China
• HS Code：84779000
• Production Capacity：20units

CONTAINER
Theoretical output
3000
4000
6000
8000
Max.container volume
2L
2L
0.7L
0.7L
Max.neck diameter
38mm
38mm
38mm
38mm
Max.container diameter
105mm
105mm
70mm
70mm
Max.container height
335mm
335mm
250mm
250mm
Max.perform height
150mm
150mm
130mm
130mm
Number of cavity
3
4
6
8
ELECTRICAL SYSTEM
Motor power
3KW
3KW
3KW
3KW
Heating power
30KW
33KW
35KW
45KW
Actual total power
33KW
36KW
38KW
48KW
AIR SYSTEM
Operataiting low pressure
0.7Mpa
0.7Mpa
0.8-1.0Mpa
0.8-1.0Mpa
Low pressure consuming
0.6-0.8m3/min
0.6-0.9m3/min
0.7-0.9m3/min
0.7-1.0m3/min
Blowing pressure
3.5Mpa
3.5Mpa
3.5Mpa
3.5Mpa
High pressure consuming
2-3m3/min
3-4m3/min
4-5m3/min
5-6m3/min
CHILLER WHATER
Operating pressure
0.3-0.5Mpa
0.3-0.5Mpa
0.3-0.5Mpa
0.3-0.5Mpa
Temperature
-10°C~55°C
-10°C~55°C
-10°C~55°C
-10°C~55°C
Flow rater
40L/min
40L/min
50L/min
70L/min
MACHINE
Machine dimension
3.5x2x2.2m
4x2x2.2m
4.9x2.15x2.2m
5.5x2.2x2.2m
Machine weight
4200Kg
4800Kg
5000Kg
5800Kg
