PE Plastic Machinery Plastic Extruder
Ruian Queensense Machine Co., Ltd.- Type：PE Film Blowing Machine
- Raw Material：PE
- Maximum Folding Width of Film：600mm
- Screw Diameter：50mm
- Automation：Automatic
- Computerized：Non-Computerized
Base Info
- Model NO.：JY-SJ45
- Machine Weight：3t
- Certification：CE
- Suitable Material：LDPE,LLDPE,HDPE
- Thickness of Film：0.008-0.1mm
- Model：Simple
- Transport Package：Wooden Box
- Specification：CE
- Trademark：QUEENSENSE
- Origin：China
- HS Code：8477309000
- Production Capacity：30kg,H-50kg,H
Description
Basic Info.
Model NO. JY-SJ45 Machine Weight 3t Certification CE Suitable Material LDPE/LLDPE/HDPE Thickness of Film 0.008-0.1mm Model Simple Transport Package Wooden Box Specification CE Trademark QUEENSENSE Origin China HS Code 8477309000 Production Capacity 30kg/H-50kg/HProduct Description
Characteristics:
This machine set is used for blowing low-density polyethylene(LDPE)and high density polyethylene(HDPE)plastic film to make various vest bags and flat-rim bags which have been widely used for packing in the garment industry, textile industry, and food industry, etc.<o:p>
Main Technical Variables:
Model | JY-SJ45 | JY-SJ50 |
| Screw Diameter(mm) | 45 | 50 |
| Screw L/D | 28:1 | 28:1 |
| Screw Speed | 10-110r/min | 10-100r/min |
| Blowing film driving motor(kw) | 11kw | 15kw |
| Main Output(kg/hr) | 35kg/hr | 50kg/hr |
| Max. Width of Film(mm) | 600mm | 800mm |
| Single-sided Thickness of Film(mm) | 0.006-0.10 | 0.006-0.10 |
| Total Power (kw) | 22 kw | 28kw |
| Weight of Machine (kg) | 2200kg | 2600kg |
| Overall Dimensions(mm) | 4000*2000*2800 | 4600*2300*3800 |
