High Speed Mini HDPE LDPE PE Blown Film Extruder Agriculture Polyethylene

Ruian Queensense Machine Co., Ltd.
  • Type:PE Film Blowing Machine
  • Raw Material:PE
  • Maximum Folding Width of Film:600mm
  • Screw Diameter:50mm
  • Automation:Automatic
  • Computerized:Computerized

Base Info

  • Model NO.:QS-MN45
  • Machine Weight:1.8t
  • Certification:CE, ISO9001:2008
  • Material:HDPE&LDPE
  • Die Size:60-80mm
  • Screw Material:Sacm-645,38 Crmoala
  • Output:30,40kgs
  • Transport Package:Seaworthy
  • Specification:CE SGS
  • Trademark:QUEENSENSE
  • Origin:China
  • HS Code:847730900
  • Production Capacity:30-80kgs,H

Description

Basic Info.

Model NO. QS-MN45 Machine Weight 1.8t Certification CE, ISO9001:2008 Material HDPE&LDPE Die Size 60-80mm Screw Material Sacm-645/38 Crmoala Output 30/40kgs Transport Package Seaworthy Specification CE SGS Trademark QUEENSENSE Origin China HS Code 847730900 Production Capacity 30-80kgs/H

Product Description

High Speed Mini HDPE LDPE PE Blown Film Extruder Agriculture Polyethylene

It is used to blow low density polyethylene (LDPE), high density polyethylene (HDPE) and linear low density polyethylene (LLDPE) plastic films and other films, and is widely used in civil and industrial package such as food, clothes, garbage bags and T-shirt bags.
ModelQS-MN45QS-MN50
Suitable materialHDPE/LDPEHDPE/LDPE
Film width100-500mm100-600mm
Film thickness0.008-0.1mm0.008-0.1mm
Max. Extrusion output30kg40kg
Screw diameter4550
Screw  L/D Length28:128:1
Screw MaterialSacm-645/38 CrmoalaSacm-645/38 Crmoala
Driving motor11kw11kw
Die size50-70mm60-80mm
Roller Width600mm700mm
Typesteel roller-friction type rewindersteel roller-friction type rewinder
Winding speed5-50m/min5-50m/min
Outline Dimension(L*W*H)2300*1800*3000mm2300*1800*3000mm
Weight1.9T2.1T
