• Model NO.：SJ-PLZ series
• Specification：ISO9001: 2008
• Trademark：SANLONG
• Origin：Zhejiang, China
• Production Capacity：36 Sets Per Year

Basic Info.

Model NO. SJ-PLZ series Specification ISO9001: 2008 Trademark SANLONG Origin Zhejiang, China Production Capacity 36 Sets Per Year

Product Description

Specifications

Compact, pleasing appearance, smooth running, flexible and reliable control, excellent automattic performance



High speed flat film plastic tape extrusion machine
The plastic tape extrusion plant has the performance of high speed, high production, low energy consumption, and excellent good forming quality.

The structure of the machine line is compact with a pleasing appearance, smooth running, flexible and reliable control, excellent working performance, convenient and safe operation. It is equpped with highly automatic industrial controlling components and electric parts.

It can be applied in many aspects, especially in various flat yarn forming conversion of thermoplastics, such as PP, HDPE, LDPE, etc. It is mainly used for plastic woven bags, jumbo bags, FIBC, geotextile, artifical grass, base material of carpet.

Item Type	Max. extrusion capacity (kg/h)	Driving power of extruder (kw)	Screw diameter (mm)	Ratio Of L/D	Rotational Speed of screw (r/min)	Die Lip width (mm)	Max Line Speed (m/min)	Plastic Tape Titer Scope (tex)	Stretched Ratio	Winders Number (Spindles)
SJ-PLZ-70/33/850	180	45	70	33: 1	20--120	850	250	60--200	4-10	144
SJ-PLZ-90/33/1000	280	90	90	33: 1	20--120	1000	280	60--200	4-10	176
SJ-PLZ-100/30/1000	350	90	100	30: 1	20--120	1100	280	60--200	4-10	192
SJ-PLZ-120/30/1500	490	160	120	30: 1	20--120	1500	280	60--200	4-10	256
