Hot Feed Rubber Extruder /Cold Feed Rubber Extruder
Qingdao Yadong Machinery Group Co., Ltd.- Type：Pipe Extruder
- Screw：Single-Screw
- Automation：Automatic
- Computerized：Computerized
- Transport Package：Wooden Case
- Specification：ISO STANDARD
Base Info
- Model NO.：XJW
- Trademark：Judong
- Origin：China
- HS Code：84778000
- Production Capacity：1000,Years
Description
| Type | XJW-90 | XJW-120 | XJW-150 |
| Screw Dia.(mm) | 90 | 120 | 150 |
| Max. Screw Speed (r/min) | 45 | 40 | 35 |
| Feeding Roll Dia. (mm) | 72 | 120 | 120 |
| Motor Model & Power | Motor Z4, the power will be decided according to the extrusion head equipped. | ||
| Zone of Hot Water Circulating | 3-4 | 3-4 | 3-4 |
| Max. Total Power of Hot Water Circulation Heating (KW) | 48 | 48 | 48 |
| Capacity (Kg/h) | It will be decided according to the extrusion head equipped. | ||
| Overall Dimensions(mm) (Without extrusion head and hopper) | 3045x2052x1453 | 4250x2290x1490 | 4277x2211x1503 |
| Weight (Kg) | 5000 | 5500 | 8000 |
