Mini Type Blow Machine
Ruian Queensense Machine Co., Ltd.- Type：PE Film Blowing Machine
- Raw Material：PE
- Maximum Folding Width of Film：600mm
- Screw Diameter：50mm
- Automation：Automatic
- Computerized：Computerized
Base Info
- Model NO.：QS-MN50
- Machine Weight：1.8t
- Certification：CE
- Material：HDPE&LDPE
- Die Size：60-80mm
- Screw Material：Sacm-645,38 Crmoala
- Output：30,40kgs
- Transport Package：Seaworthy
- Specification：CE SGS
- Trademark：QUEENSENSE
- Origin：China
- HS Code：847730900
- Production Capacity：30-80kgs,H
Description
Basic Info.
Model NO. QS-MN50 Machine Weight 1.8t Certification CE Material HDPE&LDPE Die Size 60-80mm Screw Material Sacm-645/38 Crmoala Output 30/40kgs Transport Package Seaworthy Specification CE SGS Trademark QUEENSENSE Origin China HS Code 847730900 Production Capacity 30-80kgs/HProduct Description
It is used to blow low density polyethylene (LDPE), high density polyethylene (HDPE) and linear low density polyethylene (LLDPE) plastic films and other films, and is widely used in civil and industrial package such as food, clothes, garbage bags and T-shirt bags.
| Model | QS-MN45 | QS-MN50 |
| Suitable material | HDPE/LDPE | HDPE/LDPE |
| Film width | 100-500mm | 100-600mm |
| Film thickness | 0.008-0.1mm | 0.008-0.1mm |
| Max. Extrusion output | 30kg | 40kg |
| Screw diameter | 45 | 50 |
| Screw L/D Length | 28:1 | 28:1 |
| Screw Material | Sacm-645/38 Crmoala | Sacm-645/38 Crmoala |
| Driving motor | 11kw | 11kw |
| Die size | 50-70mm | 60-80mm |
| Roller Width | 600mm | 700mm |
| Type | steel roller-friction type rewinder | steel roller-friction type rewinder |
| Winding speed | 5-50m/min | 5-50m/min |
| Outline Dimension(L*W*H) | 2300*1800*3000mm | 2300*1800*3000mm |
| Weight | 1.9T | 2.1T |
