Plastic Bottle Blowing Molding Machine Price
Jiangsu Faygo Union Machinery Co., Ltd.- Type：Stretch Blow Molding Machine
- Cavity Number：4
- Hourly Output：7200bottles,Hour(@500ml)
- Working Power：26kw
- High Pressure Require：6m3,30bar
- Motors：Servo Motor Control
Base Info
- Model NO.：4 cav
- Blowing Valve：American Parker
- Electrical Element：Mistubishi,Siemens
- Raw Material：Pet
- Making Method of Parison：Stretch Blow
- Automation：Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008
- Transport Package：Covered by PE Film
- Specification：FG-4
- Trademark：Faygo
- Origin：Jiangsu Zhangjiagang
- HS Code：84779000
- Production Capacity：6800-7200bph
Description
Main ParameterModel FG-4(4 cavity) Capacity Depend on bottle design 9600-10000PCS/H Applicable Preform Height <330mm Neck 20mm-25mm Applicable Bottle Neck 20-25mm Volume Max. 2Liter Height Max. 328mm Diameter Max. 105mm Electric consumption Install power 51kw Heating oven powder 46kw Heating Oven operating power 26kw Air consumption Pressure 6m3/min 3.0MPa Capacity 6m3/min 3.0MPa Mold Chiller Pressure 4-6Bar Temperature 6-13ºC Flow 45L/min Oven Chiller Pressure 4-6Bar Temperature 6-13ºC Flow 26L/min Machine Dimension L*W*H 3900*900*2500mm Weight 3500kg Capacity: 5000-5500BPH(based on 1L) Max. Volume: 2 Litter
Total Size:
Blowing Main machine: 3.6*1.3*2.3m
Sorting machine: 2*1.5*1.5m/Loader: 3*1*1.5m
Main electricsElectric part PLC Japan Mitsubishi Servo System Japan Panasonic Frequency inverter Japan Mitsubishi Operating system Japan Mitsubishi Touch screen Japan Mitsubishi Blowing Valve Japan Parker Reducing Valve German DURAY Note: All the electrical components adopts CE, UL, CCC approved international
Advanced high-tech product
II. Technical Features:
1. Servo driving and cam linking movement blowing section:
The unique cam linking system integrates mold-opening, mold-locking and bottom mold-evevating in one movement, equipped with high speed
servo motor, which greatly shortens the blowing cycle and accelerates the spped.
2. Minimize distance of heating heads,maximize the heating efficiency.
Heater distance in the heating oven is minimized to 38.1mm, compared with the conventional heating oven it can save more than 30%
consumption.Equipped with the air cycling system and redundant heating discharge system it ensures constant temperature in the heating zone.
3. Efficient and soft perform inlet system,ensure the spped and preform protction.
By rotary and soft preform loading system, the speed of preform feeding is ensured, meanwhile, the preform neck is well protected.
4. Modularized design conception, convenient for maintenance and changing changeovers
The machine adopts modularized design concept to make it convenient and cost-saving for the maintenance and changing changeovers.
One Stop Station Services
1) Stand-by engineers team to provide overseas installation and commissioning service.
2) 1 year warranty. During warranty, we provide free of charge for repairing cost.
3) Lifetime maintenance. After-sales department can provide life long maintenance service.
