- Model NO.:DX-1000
- Computerized:Non-Computerized
- Certification:ISO9001:2008, CE
- Fan Power:3-6kw
- Motor Power:7.5-30kw
- Motor Band:Siemens
- Voltage:380V 50 Hz 3p or Customized
- Blade Quantity:68-96PCS
- Speed:500rpm
- Inverter:ABB Siemens Schneider or Required
- Transport Package:Wood Base and Wood Case
- Specification:stainless steel 304
- Trademark:DEEDO
- Origin:Zhangjiagang City, China
- HS Code:84778000
- Production Capacity:80 Sets,Year
1 | Model | DD1000 |
2 | Main Motor power | 30KW |
3 | Production capacity | 1000kg/hour |
4 | Diameter of main shaft | 219mm |
5 | Working method | By Spiral friction separation and air sucking |
6 | Clean Ratio for label remove | 97% clean for label removing |
7 | Weight | 2500kg |
8 | Overall dimension | 4000X2200X1800mm (L*W*H) |
9 | Height under machine | 1000mm |
10 | There are 2pcs absorb label fans. Motor | 4KW/pcs ;totally 8kw for two sets of air blow for suck label |
11 | Rotary speed for main shaft | 480rpm |
12 | Rotary diameter for main shaft | 600mm |
13 | Effective length of chamber | 3500mm |
14 | Collect label ways | customized mesh bag |
15 | The material of knife rest | steel casting |
16 | The material of knife | tungsten steel |
17 | The main body material | A3 |
18 | The advantage of remove the label for triaxial | It use 3 times remove label, make bottle label thoroughgoing separate,it reach to 100% . |
19 | Knife can dismantle | Yes |
Three Shaft PET Bottles Label Remover Machine
1 | Model | DD1000 |
2 | Main Motor power | 30KW |
3 | Production capacity | 1000kg/hour |
4 | Diameter of main shaft | 219mm |
5 | Working method | By Spiral friction separation and air sucking |
6 | Clean Ratio for label remove | 100% clean for label removing |
7 | Weight | 3500kg |
8 | Overall dimension | 4000X2200X2600mm |
9 | Height under machine | 1000mm |
10 | There are 3pcs absorb label fans. Motor | 4KW/pcs ;totally 12kw for three set of air blow for suck label |
11 | Rotary speed for main shaft | 480rpm |
12 | Rotary diameter for main shaft | 600mm |
13 | Effective length of chamber | 3500mm |
14 | Collect label ways | customized mesh bag |
15 | The material of knife rest | steel casting |
16 | The material of knife | tungsten steel |
17 | The main body material | A3 |
18 | The advantage of remove the label for triaxial | It use 3 times remove label, make bottle label thoroughgoing separate,it reach to 100% . |
19 | Knife can dismantle | Yes |
plastic bottle label remover machine parameter:
Model | Capacity | Power | Fan Power | Label Separation Rate | Appliction |
LMD-11 | 300~500kg | 7.5KW | 3KW | > 98% | 500 kg/h pet washing line |
LMD-22 | 1000-1500kg | 22KW | 3KW+3KW | > 98% | 1000 kg/h pet washing line |
LMD-30 | 2000-3000kg | 30KW | 4KW | > 98% | 2000 kg/h pet washing line |
