5L Oil Bottle Blower Machine
Zhangjiagang Glory Machinery Co., Ltd.- Type：Stretch Blow Molding Machine
- Raw Material：PET
- Making Method of Parison：Stretch Blow
- Automation：Non-Automatic
- Computerized：Non-Computerized
- Max Size：5L
Base Info
- Model NO.：GMS-5L
- Cavity：2
- Cylinder：Airtac
- Power：22kw
- Transport Package：Wooden Case
- Specification：2cavity
- Trademark：GM
- Origin：China
- HS Code：8477301000
- Production Capacity：50sets,Year
Description
Main parameter:Model GMS-5L Container Product material PET Volume 5L-10L Theoretical output 300-500PCS/H Preform length 15mm-460mm Preform inner diameter Φ15mm-200mm Moulding Max.mould plate Dimenstion(L x W) 470x500mm Max.mould thickness 370mm Clamping force 100KN Mould opening stroke 350mm Machine size and weight Main machine (L x W x H) 193*72*183cm Main machine weight 800Kg Heater (L x W x H) 187*63*145cm Heater weight 250Kg Power 17.5kw
Trait:
GMS-5L semiautomatic bottle blow molding machine is suitable for producing PET plastic containers and bottles from 5000-10000ml. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle etc.
Adopting double crank to adjust mould ,heavy locking mould, stable and fast ,Adopt infrared oven to heat the perform ,the perform rotated and heated equally.
The air system has been divided into two parts: pneumatic action part and bottle blow part to meet the different requirements for the action and blow. It can provide sufficient and steady high pressure for blowing large irregular shaped bottles.
The machine is also equipped with muffler and oiling system to lubricate the mechanical part of the machine.
The machine can be operated in the step-by-step mode and the semi- auto mode.
The machine is small with low investment, easy and safe to operate by one person.
