• Model NO.：YCQ-5L-1
• Color：Orange
• Application：Plastic Bottle
• Max.Volume：5L
• Cavity：1
• Theory Output：1000~1600bph
• Size of Machine：1.56*0.7*1.9(M)
• Weight of Machine：700kg
• Size of Oven：1.45*0.65*1.15(M)
• Weight of Oven：330kg
• Bottle Material：Pet
• Transport Package：Wooden Package,According to Customer′s Request
• Specification：CE ISO
• Trademark：Eceng
• Origin：Zhangjiagang Jiangsu
• HS Code：8477300000
• Production Capacity：100per Year

Basic Info.

Model NO. YCQ-5L-1 Color Orange Application Plastic Bottle Max.Volume 5L Cavity 1 Theory Output 1000~1600bph Size of Machine 1.56*0.7*1.9(M) Weight of Machine 700kg Size of Oven 1.45*0.65*1.15(M) Weight of Oven 330kg Bottle Material Pet Transport Package Wooden Package/According to Customer′s Request Specification CE ISO Trademark Eceng Origin Zhangjiagang Jiangsu HS Code 8477300000 Production Capacity 100per Year

Product Description

Technical Parameter

Main machine  (blowert + oven)	Model type	Tech data
Product Spec	Max. product volume(L/cav)	5.5
	Max. preform neck size(mm)	150
	Max. product diameter(mm)	200
	Max. product height (mm)	400
	Cavities	1
Blow molding part	Die force (KN)	120
	Die stroke (mm)	320
	Max. mould size(mm)	390*350
	Mould thickness	Adjustable
	Mould spacing(mm)	Adjustable
	Max. pulling stroke(mm)	500
	Operation pressure(Mpa)	0.8-1.0
	Operation air pressure consumption(1tr/min)	350
	Blow pressure(Mpa)	1.2-2.8
	Blow air pressure consumption (1tr/min)	300
	Output(pcs/h)	1000-1600
	Machine size(LxWxH)(m)	1.5*0.7*1.9
	Machine weight(KG)	700
Oven	Temperature grade(rate)	8
	Heating time(S)	90-200
	Voltage(V)	220 or as your request
	Frequency(HZ)	50/60
	Total power(KW)	16
	Oven Size (LxWxH)	1.45*0.65*1.15
	Oven weight (KG)	330

Main Feature

 1.Using the new clamping system with double crank four tie-bars,the cross balanced fixed glide.

 2.The seal,the stretch use the parallel bars union and combined design,which is advantageous to the product  formation.

 3.The advanced air course design,the single-channel air admission;Low pressurefor clamping, sealing and  stretching;the high pressure for blowing the bottle.

 4.PLC control system, the operation is easy.

 5.With infrared heating,controllable constant pressure control,frequency conversion,thus achieves blows the  perfect bottle.

Our service



1) Stand-by engineers team to provide overseas installation and commissioning service.



2) 1 year warranty. During warranty, we provide free of charge for repairing cost.

3)  Lifetime maintenance. After-sales department can provide life long maintenance service.



FAQ

 Q: Your company is a transactional company or an industrial manufacture factory?



A: We are an industrial manufacture factory which locates in Zhangjiagang city.



Q:All of your products are made by your self or compacted via purchasing the others?



A: We have independent technical team who focus on making machines, all the products are made by our technical team.



Q:Do you have any other services about your products?



A:We have a lot of experience on making projects and specifications for our clients, also we have a fixed service system.



Q:How do you make the quotation for clients?



A:The price depends on quality and performance but the clients should be satisfied first.

After-sales service
1.we will provide the bill of load on time to make sure you can get the machine quickly
2.when you finish the Preparation conditions ,our engineer will go to your factory to install the machine ,and give you the operating manual ,and train your employee until they can operate the machine well.
3.we provide one year warranty with spare parts free.
The sample service
1.we can send you the video of the running machine.
2.you are welcome to come to visit our company,and see the machine running in our factory,we can pick you up from the station near our city.
3.If we get  the permission of the customer who has brought the machines from us ,we can tell you their contact imformation,you can go to vist their factory.
Customized service
1.we can design the machines according your requirements(materil ,power,filling type,the kinds of the bottles,and so on).
2.at the same time we will give you our professional suggestion,as you know,we have been in this industry for many years.
