Plastic Machinery

2 Layer Co-Extruding Rotary Head Film Blowing Machine

Ruian Xinye Packaging Machine Co., Ltd.
  • Type:PE Film Blowing Machine
  • Raw Material:PE
  • Maximum Folding Width of Film:1500mm
  • Screw Diameter:55mm
  • Automation:Automatic
  • Computerized:Computerized

Base Info

  • Model NO.:SJ-55x2,FM1500
  • Machine Weight:5.2t
  • Certification:CE
  • Rewinder:Single Rewinder
  • Die-Head:Rotary
  • Air Ring:Single Air Vent
  • Corona Treater:Can Be Chosen
  • Transport Package:in Standard Wooden Case
  • Specification:5200*2700*6000mm
  • Trademark:Elight
  • Origin:Zhejiang, China
  • HS Code:8477309000
  • Production Capacity:50sets,Year

Description

ModelSJ-45x2/FM1000SJ-50x2/FM1200SJ-55x2/FM1500Screw Diameter45mm50mm55mmScrew RatioL/D28:1L/D28:1L/D28:1Screw Speed15-120r/min15-120r/min15-120r/minPower of Main Motor11kwx215kwx215kwx2Die-head¢200¢300¢350Output75kg/h100kg/h120kg/hThickness of Film0.02-0.10mm0.02-0.10mm0.02-0.10mmMax. Folding Width1000mm1200mm1500mmTotal Power52kw63kw75kwWeight of Machine3500kg4500kg5200kgOverall Dimension4200*2200*4600mm4600*2400*5000mm5200*2700*6000mm



Company Information
   Xinye packaging machine company with a long history is located in Rui'an, Zhejiang Province. We specialize in producing series of packaging equipment, like bag making machines, printing machines, film blowing machines and material cutting and punching machines. Taking sincerity and credit as the most important factors for success, we will do our almost to improve product quality and perfect our service system. We welcome all friends to visit us for future cooperation.


Our Services:
Installation Services:
     Installation Services are available with all new machine purchases. We will provide the technical know-how for your operation smooth transition and support for installing, debugging, operation of the machine, it will indicate you how to use this machine well.
After Sales Service:
     We offer the Preventative Maintenance and After Sales Service. For we strongly feel that importance of supporting our customers and the product solutions we provide. Consequently we offer comprehensive maintenance options to prevent equipment issues before they become problems. Also we offer one year guarantee period.
