Mini Type Film Blowing Machine (MD-HM35)

Ruian Mingde Machinery Co., Ltd.
  • Type：PE Film Blowing Machine
  • Raw Material：HDPE
  • Maximum Folding Width of Film：600mm
  • Screw Diameter：45mm
  • Automation：Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：MD-HM35
  • Machine Weight：1000kgs
  • Certification：CE, ISO9001:2008
  • Color：Green
  • Main Motor：Siemen
  • Frequency Inverter：Taiwan Delta
  • AC Contactor：Ls
  • Transport Package：Nude Packing,Wooden Case
  • Specification：CE, ISO9001
  • Trademark：Mingde
  • Origin：China
  • HS Code：8477209000
  • Production Capacity：100sets,Year

Description

Extrusion UnitHard-face Gear Case133Screw DiameterΦ35mm from Zhoushan ChinaScrew Material38 CRMOALA
38 CRMOALABarrel's MaterialScrew L/D30:1Main Motor Power7.5kwFrequency inverterFrom DeltaCylinder Cooling250wx1Thermo Control (zone)2Extrusion DieDie Size  HD:50mmScreen ChangerStandard ManualThermo Control (Zone)2Air Ring(mm)Φ470Cooling Blower(kw)1.1Center Steady Stick1 pcsTake-up UnitTraction Roller Widthφ138×450mmEmbossing Roller Width350mmTake up Motor(kw)0.75Take Up Speed10-80m/minWinding UnitRewinding TypeSingle Rewinder.Surface Friction WinderRewinding shaftAir expanding shaftRoller Width450mmWinding Motor10N.MRewinding Speed10-80m/minVoltage380V,50HZ,3PHASEMachine Dimension1400x2000x3200(mm)
