• Model NO.：SJ-
• Computerized：Computerized
• Machine Weight：1.5t
• Certification：CE, ISO9001:2008
• Output：25-55kg,Hr
• Rotary Die Head：Optional
• Embossing：Optional
• Die Head：2 Free
• Transport Package：Film Package
• Specification：SGS
• Trademark：YUNBANG
• Origin：China
• HS Code：84778000
• Production Capacity：20 Sets,Month

Basic Info.

Model NO. SJ- Computerized Computerized Machine Weight 1.5t Certification CE, ISO9001:2008 Output 25-55kg/Hr Rotary Die Head Optional Embossing Optional Die Head 2 Free Transport Package Film Package Specification SGS Trademark YUNBANG Origin China HS Code 84778000 Production Capacity 20 Sets/Month

Product Description

Main Technical Variables:

Model	55	-65	80	100
Screw  Diameter	55mm	65mm	80mm	100mm
Screw  Ratio	L/D28:1	L/D28:1	L/D28:1	L/D28:1
Screw  Speed	10-100r/min	10-100r/min	10-100r/min	10-100r/min
Main  Output	50kg/h	70kg/h	86kg/h	140kg/h
Power of  Main Motor	15KW	22KW	30KW	45KW
Specification of Die Head	¢100-¢150mm	v120-¢220mm	¢150-¢300mm	¢500mm
Rotational Mode of Machine Head	constantly revolve	constantly revolve
Single-sided Thickness of Film	0.01-0.10mm	0.01-0.10mm	0.01-0.10mm	0.01-0.10mm
Max.Folding Width of Film	800mm	1200mm	1500mm	2000mm
Electric Total Capacity	26Kw	42Kw	56Kw	880Kw
Weight of Mashine	2300kg	3800kg	4600kg	6000kg
Overall Dimensions(mm)	6000x2000x4000	6800x2400x4800	7000x2700x5500	8000x3200x7600

Q&A:

1. How long will your engineer reach our factory?
Within one week after machine arrival your factory.

2. How many days will you finish installing?
We will finish installation and training within 15days.

3. What should we charge for your engineer?
You should charge for the cost of our engineer's visa, air tickets, hotel, food, and also their salary 100USD one day per person.

4. How long is your machine's warranty period?
All our machine have one year guarantee, starting from finished installation.

5. How could we do after one year warranty period?
We also can do service for you, but you need pay salary for my technician 80USD/day.

6. How could we do if the parts broken within warranty?
We would express the free replacement parts during the warranty date.

7. Does your engineer understand English?
Our engineers understand a little English. All of our engineer have more than five years machine installation experience. In addition, they can use body language to communicate with customer.

8. Can you help us find any engineer in our location?
Of course, we will check and inform you as soon as possible.
