• Model NO.：PC230-PC1000
• Computerized：Computerized
• Certification：CE, ISO9001:2008
• Delivery Time：30 Days
• Inverter：AC
• Cabinet Electric Parts：ABB Siemens Schneider
• Motor：Siemens
• Voltage：380V 50 Hz or Depends Required
• Material Type：Pet PE PP PVC ABS Pet PV EPS
• Machine：Plastic Bottle Grinder Machine
• Using：Pet PE Plastic Bottle Crusher
• Transport Package：Wood Base and Wood Case
• Specification：PP PE PVC ABS PET
• Trademark：DEEDO
• Origin：Zhangjiagang City, China
• HS Code：84778000
• Production Capacity：200 Sets,Yesr

Basic Info.

Model NO. PC230-PC1000 Computerized Computerized Certification CE, ISO9001:2008 Delivery Time 30 Days Inverter AC Cabinet Electric Parts ABB Siemens Schneider Motor Siemens Voltage 380V 50 Hz or Depends Required Material Type Pet PE PP PVC ABS Pet PV EPS Machine Plastic Bottle Grinder Machine Using Pet PE Plastic Bottle Crusher Transport Package Wood Base and Wood Case Specification PP PE PVC ABS PET Trademark DEEDO Origin Zhangjiagang City, China HS Code 84778000 Production Capacity 200 Sets/Yesr

Product Description

Product Description

High Performance Plastic Crusher Machine Grinder machine

Plastic type: PE, PP, PET, PVC, ABS and others hard plastics
DD series crusher is one kind economical crusher.All the blades adopt imported high quality tool steel  which is especially durable.The installation of the blade can be adjusted and can be sharpened and sharpened again and again.All you need is a sharpener for blade.
The rotary blade stand is a step design to make cutting resolve and increase the cutting force times.
The material of all the blade are D2.Its hardness and softness is very good.it is not easy to broken or worn.
The main body adopt very good quality steel to make sure that the machine is used for a long time and affect its mechanical performance
The axle core of the machine is fished process once to ensure concentric circle and verticality is not large than 0.05mm.
Each part has reference hole.Twice rough fish and fine finishing are carried out.The part has strong changeability and high precision.
Application: plastic case, thin pipe fitting, blow molding pieces,bottle and shell etc.


DD series crusher blade adopt D2 material,choose suitable structure blade roller can  improve the capacity and quality of crusher.According to the different materials,you can choose different types of blade shaft.Mechanical electrical through multi-protection can increase equipment working lifetime greatly.
Application:plastic bottle,film,packing case,sheet stock,lump material,rubber,wood etc.


Technology parameter:

Model	Capacity	Rotary blade	Fixed blade	Size of entrance	Dia.of screen	Power
SHTW-500B	300-400kgs/h	6 pcs	4 pcs	500x400mm	12mm	11kw
SHTW-650B	500-600kgs/h	6 pcs	4 pcs	650x400mm	12mm	18.5kw
SHTW-800B	700-800kgs/h	6 pcs	4 pcs	800x500mm	18mm	30kw
SHTW-1000B	900-1000kgs/h	6 pcs	4 pcs	1000x650mm	20mm	45kw
SHTW-1200B	1100-1200kgs/h	6 pcs	4 pcs	1200x660mm	22mm	55kw
SHTW-1000 I	1000-1100kgs/h	15 pcs	4 pcs	1000x650mm	16mm	45kw
SHTW-1200 I	1150-1250kgs/h	18 pcs	4 pcs	1200x660mm	16mm	55kw

 Our Services

1.We supply one year guarantee for all of our machines.
2.We free supply 2 years normal spare parts for all of our machines.
3.24 hours service.
5.After service is full life of machine.

All of our machines design and produce according to the CE standard.
When the machines are ready,our workshop director will run and check first,if it is ok,then
our QC department will testing it again to ensure the machine is runing and working well.
Then we will send the testing report to client for confirmation.
Our principle: only after testing, machine can leave the factory. and only qualified, it can be delivered.
