3600PCS/H Pet Preform Injection Molding Production Line

Zhangjiagang Glory Machinery Co., Ltd.

Type：Preform Injection
Structure：Horizontal
Plastic Type：Thermoplastic
Plasticizing Way：Plunger Type
Clamping Way：Hydraulic & Mechanical
Automation：Automatic

Base Info

Model NO.：GM-2300
Computerized：Computerized
Peform：Pet
Motor：Brand
Automatic：Yes
Voltage：380V
Transport Package：Wooden Case
Specification：5500
Trademark：GM
Origin：China
HS Code：8477101090
Production Capacity：10sets,Year

Description

60Screw L/D--21Shot weightgram720Injection capacitycm3791Injection pressurekg/cm21760Screw strokemm280 Screw torqueN.m2000 Heating powerkw18.5 Clamping forceton240 Opening strokemm530 Mould heightmm200~570 Max daylightmm1100 Space between tie barsmm555×555 Ejector force/stroketon/mm6.15/130 Oil pump motorkw22 Machine sizem6.2×1.6×2.1 Machine weightton8
Configuration specification

Name	Brand	Origin
hydraulic proportional valve	YUKEN	JA PAN
Hydraulic Oil Pump	HIGH-TECH	TAI WAI
ReversalHydraulicValve	YUKEN	JA PAN
Hydraulic Motor	ZY	Italy-China
Hydraulic Hose	Kim ber lery
Sealing Rings	VALQUA	JA PAN
Computer	JINHUA TECHMATION	TAI WAN
Linear Transducer	MI RAN	CHI NA
Limit Switch	panasonic	JA PAN
Proximity Switch	FORTEK	TAI WAN
Solid State Relay	FORTEK	TAI WAN
Contactor	LG/SCHNEIDER	KOREA/FRANCE
High-temperature Wire		CHINA
Air-break Switch	LG/FUJI	KOREA

3600PCS/H Pet Preform Injection Molding Production Line

3600PCS/H Pet Preform Injection Molding Production Line
