Taiwan Quality, 5 Years Warranty, ABA Three Layers Co-Extrusion Film Blown Machinery

HEBEI CHENGHENG PLASTIC MACHINERY TECHNOLOGY CO., LTD.
  • Type：High and Low Pressure Film Blowing Machine
  • Raw Material：HDPE
  • Maximum Folding Width of Film：1200mm
  • Screw Diameter：65mm
  • Automation：Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：CHSJ-50,55R
  • Machine Weight：4T
  • Certification：CE, ISO9001:2008
  • Extrusion Capacity Kg/H：98-120kg
  • Material：LDPE,HDPE,LLDPE,Mlldpe
  • Film Width(Folding Diameter)：300-1200mm
  • Packing Details：Wooden Cases
  • Delivery Time：20-25 Working Days
  • Film Thickness(mm)：0.007-0.05
  • Traction Speed M：15-70,Min
  • Payment Term：T,T
  • Transport Package：Wooden Cases
  • Specification：SGS
  • Trademark：CHENGHENG
  • Origin：China
  • HS Code：8477309000
  • Production Capacity：50set,Year

Description

CHSJ-50BCHSJ-55BDiameter of screw50mm ×265mm×2L/D ratio of screw30:128:1Main motor power (KW)Level 415×2Level 422×2Heating power(KW)23.425Film width(folding diameter)300-800300-1200Film thickness(mm)0.007-0.050.007-0.05Extrusion capacity kg/h98kg120kgMaximum rotation speed of screw120/min120/minTraction speed M15-70/min15-70/minWinding speed M30-80/min30-80/minRaw materialLDPE,HDPE,LLDPE,MLLDPEMachine power(KW)37.540Overall dimension4.5×3.2×3.84.5×3.6×4.5Weight3.5T4.2T
Service:

1.Free installation and ajustment.(for consumers purchase more than $100000 only)
2.Five years free after-sales service and mechanical parts lifetime warranty.
3.We will offer you the professional answers about the relating machines in 24 hours.
