UPVC PVC Three Layer Roof Tile Making Machine
GPM Machinery (Shanghai) Co., Ltd.- Product Type：PVC Board
- Board Layers：Single Plate
- Screw No.：Double-screw
- Automation：Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008, UL, QS, GMP
Base Info
- Model NO.：GYF1220
- Customized：Customized
- Condition：New
- Product Name：UPVC PVC Three Layer Roof Tile Making Machine
- Processing Type：Tile Extrusion
- Raw Material：PVC Powder
- Usage：Roof Tile
- Motor：Simens
- Inverter：ABB Brand
- Contactor：France Schneider Contactors
- Temperature Control：Japan Omron
- Output：250-550kg,H
- Motor Power：37kw-132kw
- Transport Package：PE Film Winding Wrapping
- Specification：1mm-3mm
- Trademark：GPM
- Origin：Shanghai
- HS Code：8477209000
- Production Capacity：500 Sets,Year
Description
GSZ80/156 Extruder
Supplier of electric control cabinet Main transducer and feeder's transducer: TECO; Air switch: Suzhou SIEMENS.
Extrusion capacity (kg/h) 250-350kgs/h (Max.) Outer Size (mm) 4750mmX1550mmX2460mm Total Weight (Kg) 5000Kg Hopper Taper 60° Inlet wire terminal of power resource Three-phase four-wire system Manufacture of the motors, pumps
The main AC motor: 55KW; Motor for feeder: 0.55KW
Type of Temperature control curve Temperature fluctuating self-adjusting (PID Type)
Pressure Display With melt pressure display Type of the feeder Spiral spring feeder Connection of die head with flange By bolts The display method of data in operating panel Mainly digital display
2. Machine list:
2. Machine list:
| Item | Equipment | Quantity |
| 1 | GSZ80/156 Conical Twin-screw Extruder GSZ80/156 | 1 Unit |
| 2 | T-die Sheet Tooling (1300mm) T(1300mm) | 1 Unit |
| 3 | Calibration Tooling | 2 Units |
| 4 | Haul-off Machine | 1 Unit |
| 5 | Guillotine | 1 Unit |
| 9 | Stacker | 1 Unit |
