• Model NO.：SJSZ 65,132
• Raw Material：P,PE,PVC+Wood Power
• Max.Cutting Section(L*W)：240*65mm
• Production Line Speed：0.5-1.5m,Min
• Capacity：180-500kg,Hr
• Dimension(L*W*H)：20*3*3
• Installation Power /Power Consumption：125kw,85kw
• Weight：15t
• Power Supply：380V Three Phase 50Hz or as Per Your Request
• After-Sales Service Provided：Engineers Available to Service Machine Overseas
• Transport Package：PE Elastic Film or Wooden Case
• Specification：As per customer′s request
• Trademark：WEIER
• Origin：Qingdao, China
• HS Code：84772090
• Production Capacity：1000 Sets Year

Basic Info.

Model NO. SJSZ 65/132 Raw Material P,PE,PVC+Wood Power Max.Cutting Section(L*W) 240*65mm Production Line Speed 0.5-1.5m/Min Capacity 180-500kg/Hr Dimension(L*W*H) 20*3*3 Installation Power /Power Consumption 125kw/85kw Weight 15t Power Supply 380V Three Phase 50Hz or as Per Your Request After-Sales Service Provided Engineers Available to Service Machine Overseas Transport Package PE Elastic Film or Wooden Case Specification As per customer′s request Trademark WEIER Origin Qingdao, China HS Code 84772090 Production Capacity 1000 SetsYear

Product Description

WPC profile machine

1, Material: uses PVC,PP,PE resin or recycled plastic and plant fibre ( wood powder,chaff,straw etc.) as raw material.

2, Advantages: This kind of wood-plastic are not only very similar with natural wood in appearance and feel, but also have the same characteristics as wood of excisable, planeable,sawable, unmatched grip,low bibulous rate, good moisture resistance, mothproof,mildew resistance,good resistance to acid and alkali,anti-corrosion, and it has the feature of fire resistance. The products are non-toxic,non-polluting,environment-friendly and save-energied, without formaldehyde, benzene and ammonia and other harmful substances.

3, Application: The wood-plastic products are widely used in outdoor floor, close to water construction,balcony,landscape architecture,chairs and benches, fences, interior doors and windows, furniture, etc.

Remark:This production line can produce wpc products of different specifications only to change mold.

Equipment model	MSYF150	MSYF180	MSYF240	MSYF300
Maximum section width(mm)	150	180	240	300
Total power of auxiliaries(kw)	15	18.7	27.5	33.1
Cooling water capacity(m3/h)	5	5	5	7
Compressed air pressure (Mpa)	0.6	0.6	0.6	0.6
