WPC Door Frame Production Line
Qingdao Weier Plastic Machinery Co., Ltd.- Product Type:PVC Profile
- Screw:Double-Screw
- Automation:Automatic
- Computerized:Computerized
- Certification:CE, ISO9001:2008, UL
- Customized:Customized
Base Info
- Model NO.:SJSZ 65,132
- Machine Name:WPC-PVC Door Frame Making Machine
- Certificate:CE&ISO9001:2008
- Warranty:13monthes
- Product Size:Width of 200mm ( Adjustable by Changing Mold Size)
- Material:PVC Powder+ Wood Powder +Additives(After Mixing)
- Production Line Speed:0.5-1.5m,Min
- Gas Consumption:0.4m 3 ,Min
- Air Pressure:0.6MPa
- Water Supply:Water Used for Industry, No Impurities
- Work Environment Temperature:0-40°c
- Transport Package:PE Elastic Film or Wooden Case
- Specification:CE, ISO9001: 2008, SGS
- Trademark:WEIER
- Origin:Qingdao, China
- HS Code:84772090
- Production Capacity:10sets,Month
Description
Basic Info.
Model NO. SJSZ 65/132 Machine Name WPC-PVC Door Frame Making Machine Certificate CE&ISO9001:2008 Warranty 13monthes Product Size Width of 200mm ( Adjustable by Changing Mold Size) Material PVC Powder+ Wood Powder +Additives(After Mixing) Production Line Speed 0.5-1.5m/Min Gas Consumption 0.4m 3 /Min Air Pressure 0.6MPa Water Supply Water Used for Industry, No Impurities Work Environment Temperature 0-40°c Transport Package PE Elastic Film or Wooden Case Specification CE, ISO9001: 2008, SGS Trademark WEIER Origin Qingdao, China HS Code 84772090 Production Capacity 10sets/MonthProduct Description
WPC PVC door frame production lineWith special designed screw, barrel. Moule and producing process, equipped with YF series downstream equipment, this line can produce PE PP PVC and wood powder profile. This is a new kind of environmental freindly building material. Mixing the plastic, wood powder, foam agent and other additives. After high temperature and high pressure extrusion, the products can be used for pallets, packing plates, windows and door frames, decoration panels and etc.
This machine line we have sold to many countries. Like Russia, Iran, Mexico, Poland, Romania, india, Australia, Singapore, Ecuador, Canada, Uzbekstan, Malaysia, Indonesia
Description | Parameters |
Product size | Width of 200mm (can be changed by changing mold size) |
Material | PVC powder+ wood powder +additives(after mixing) |
Production line speed | 0.5-1.5m/min |
Max. output | 240kg/h |
Overall dimensions | 20m×3.5m×3m (L×W×H) |
Weight(Approx) | 12T |
Total installed power | 125kw |
Actual energy consumption power | 85kw |
Gas consumption | 0.4m 3 /min |
Air pressure | 0.6mpa |
Water circulating device | 0.5m 3 /min |
Electric condition | 380V/3P/50Hz |
Water supply | Water used for industry, no impurities, by filtrating, water pressure: 0.4mpa water temperature14~25°C |
Work environment temperature | 0-40°C |
