PPR Plastic Pipe Machine/PPR Water Supply Pipe Extrusion Line Machine Qingdao Manufacture
QINGDAO TRUSTY PLASTIC MACHINERY CO., LTD.- Product Type：PE Pipe
- Screw No.：Single-screw
- Automation：Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008
- Customized：Customized
Base Info
- Model NO.：SJ-65
- Condition：New
- Length(M)：30
- Width(M)：2
- Height(M)：3.5
- Contactor：Siemens
- Converter：ABB
- Teperature Contorller：Delta
- Motor Type：Sj-65
- Motor Power：37kw
- Capacity：150-200kg,H
- Material：Plastic Granule
- Payment：T,T
- Warranty：1 Year
- Transport Package：Wooden Packing
- Specification：50-250mm
- Trademark：Trusty
- Origin：Qingdao
- HS Code：84772090
- Production Capacity：100 Pieces,Year
Description
1.This production line adapts basket type composite die head, which ensures not only the uniformity of high speed extrusion but also the stable performance of tubular goods.
2. This production line adopts high efficiency double chamber vacuum calibrating technology and spray cooling bath to improve the rate of finished products of tubular goods and meet the demand of high-speed production. The vacuum bath and cooling bath adopt stainless steel.
3. This production line adopts multi-caterpillar haul-off and ensures the synchronization.
4. The cutting machine adopts special saw blade with low noise, equipped with chip collector.
5. The whole line adopts PLC control system and large liquid crystal screen, which makes the operation very convenient.
3.Machine List
4.Production Process
Feed→Extrude→Shape→Spray→Haul off→Print→Cut→Stack the material→Crush
5.Technical Parameter
